ASUS PRIME B550M-K ARGB, B550, AM4, DDR4, M.2, SATA, mATX

ASUS PRIME B550M-K ARGB is designed for use with AMD processors and features a Socket AM4. It supports DDR4-SDRAM memory and can accommodate a maximum internal memory of 64 GB through DIMM slots. The motherboard is compatible with both HDD and SSD storage drive types and supports M.2 storage drive interfaces. For data redundancy and performance optimization, it offers RAID levels 0, 1, and 10. The Ethernet interface type is Gigabit Ethernet, making it suitable for network connectivity requirements of modern PCs. It is a micro ATX form factor motherboard and is part of the AMD chipset family, making it an ideal component for PC builds focused on performance and versatility.

Processor

Processor manufacturer
Processor manufacturer
AMD
show more


Processor socket
Processor socket
Socket AM4
show more

Memory

Supported memory types
Supported memory types
DDR4-SDRAM
show more


Number of memory slots
2
show more


Memory slots type
Memory slots type
DIMM
show more


Memory channels
Dual-channel
show more


Supported memory clock speeds
Supported memory clock speeds
2133,2400,2666,2800,2933,3000,3200,3333,3400,3466,3600,3733,3866,4000,4133,4200,4266,4333,4400,4466,4600,4866,5100 MHz
show more


Maximum internal memory
Maximum internal memory
64 GB
show more


Unbuffered memory
Yes
show more

Storage controllers

Supported storage drive types
Supported storage drive types
HDD & SSD
show more


Supported storage drive interfaces
M.2
show more


RAID support
RAID support
Yes
show more


RAID levels
RAID levels
0, 1, 10
show more

Internal I/O

USB 2.0 connectors
USB 2.0 connectors
2
show more


USB 3.2 Gen 1 (3.1 Gen 1) connectors
USB 3.2 Gen 1 (3.1 Gen 1) connectors
2
show more


Number of SATA III connectors
Number of SATA III connectors
4
show more


S/PDIF out connector
Yes
show more


Front panel audio connector
Yes
show more


Front panel connector
Yes
show more


ATX Power connector (24-pin)
Yes
show more


CPU fan connector
Yes
show more


Number of chassis fan connectors
2
show more


12V power connector
Yes
show more


Number of COM connectors
1
show more


TPM connector
Yes
show more


RGB LED pin header
Yes
show more

Rear panel I/O ports

USB 2.0 ports quantity
USB 2.0 ports quantity
2
show more


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
show more


Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
1
show more


PS/2 ports quantity
PS/2 ports quantity
1
show more


HDMI ports quantity
HDMI ports quantity
1
show more


HDMI version
2.1
show more


DisplayPorts quantity
DisplayPorts quantity
1
show more


DisplayPort version
1.4
show more


Line-in
Yes
show more


Headphone outputs
Headphone outputs
1
show more


Microphone in
Microphone in
Yes
show more

Network

Ethernet LAN
Ethernet LAN
Yes
show more


Ethernet interface type
Gigabit Ethernet
show more


Wake-on-LAN ready
Yes
show more

Features

Motherboard chipset
Motherboard chipset
AMD B550
show more


Audio output channels
Audio output channels
7.1 channels
show more


Component for
Component for
PC
show more


Motherboard form factor
Motherboard form factor
micro ATX
show more


Motherboard chipset family
Motherboard chipset family
AMD
show more


Windows operating systems supported
Windows operating systems supported
Windows 10 x64, Windows 11
show more

Expansion slots

PCI Express x1 (Gen 3.x) slots
1
show more


PCI Express x16 (Gen 4.x) slots
1
show more


PCI Express x16 (Gen 3.x) slots
PCI Express x16 (Gen 3.x) slots
1
show more


Number of M.2 (M) slots
2
show more

BIOS

BIOS type
BIOS type
EFI AMI
show more


BIOS memory size
128 Mbit
show more


Clear CMOS jumper
Yes
show more

Packaging data

Package width
Package width
260 mm
show more


Package depth
Package depth
270 mm
show more


Package height
Package height
515 mm
show more


Package weight
Package weight
960 g
show more

Weight & dimensions

Width
Width
244 mm
show more


Depth
Depth
221 mm
show more


Height
Height
36.5 mm
show more

Packaging content

Cables included
SATA
show more

Other features

Weight
Weight
460 g
show more
