ASUS ESC4000 G4 Intel C621 LGA 3647 (Socket P) Rack 2U Black, Silver

The ASUS ESC4000 G4 features the Intel C621 motherboard chipset and is compatible with processors using the LGA 3647 (Socket P). It is designed to support the Intel Xeon Scalable processor family. This system can accommodate DDR4-SDRAM memory with module capacities of 4GB, 8GB, 16GB, 32GB, and 64GB, and supports a maximum internal memory of up to 2.05 TB. For storage, it supports drive sizes of 2.5 and 3.5 inches, and utilizes M.2 storage drive interfaces. The on-board graphics card is the Aspeed AST2500 with 64 MB of memory. Networking capabilities include Fast Ethernet and Gigabit Ethernet with supported Ethernet LAN data rates of 10, 100, and 1000 Mbit/s, facilitated by the Intel I350-AM2 LAN controller.

Processor

Built-in processor
Built-in processor
Yes
show more


Motherboard chipset
Motherboard chipset
Intel® C621
show more


Processor socket
Processor socket
LGA 3647 (Socket P)
show more


Processor family
Processor family
Intel® Xeon® Scalable
show more


Number of processors supported
Number of processors supported
2
show more

Memory

Number of DIMM slots
Number of DIMM slots
16
show more


Supported memory types
Supported memory types
DDR4-SDRAM
show more


Supported DIMM module capacities
4GB, 8GB, 16GB, 32GB, 64GB
show more


Maximum internal memory
Maximum internal memory
2.05 TB
show more


Maximum RDIMM memory
64 GB
show more

Storage

Number of storage drives supported
Number of storage drives supported
8
show more


Hot-swap HDD bays
Hot-swap HDD bays
Yes
show more


Storage drive sizes supported
Storage drive sizes supported
2.5,3.5"
show more


Supported storage drive interfaces
M.2
show more

Graphics

On-board graphics card model
On-board graphics card model
Aspeed AST2500
show more


On-board graphics card memory
64 MB
show more

Network

Ethernet interface type
Fast Ethernet, Gigabit Ethernet
show more


Ethernet LAN data rates
Ethernet LAN data rates
10,100,1000 Mbit/s
show more


LAN controller
Intel® I350-AM2
show more

Ports & interfaces

USB 2.0 ports quantity
USB 2.0 ports quantity
2
show more


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
show more


Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
3
show more


VGA (D-Sub) ports quantity
VGA (D-Sub) ports quantity
1
show more

Expansion slots

PCI Express slots version
3.0
show more


PCI Express x16 slots
8
show more

Logistics data

Harmonized System (HS) code
84714100
show more

Design

Chassis type
Chassis type
Rack (2U)
show more


Product colour
Product colour
Black, Silver
show more


LED indicators
HDD, LAN, Power
show more

Operational conditions

Operating relative humidity (H-H)
20 – 90%
show more


Operating temperature (T-T)
Operating temperature (T-T)
10 – 35 °C
show more

Weight & dimensions

Height
Height
88 mm
show more


Depth
Depth
800 mm
show more


Width
Width
440 mm
show more
