ASUS RS700-E9-RS12 Intel C621 LGA 3647 (Socket P) Rack (1U) Stainless Steel

The ASUS RS700-E9-RS12 features the Intel C621 motherboard chipset and uses the LGA 3647 (Socket P) processor socket, supporting the Intel Xeon Scalable processor family. It is compatible with DDR4-SDRAM memory types, and supports DIMM module capacities of 4GB, 8GB, 16GB, 32GB, 64GB, and 128GB, with a maximum RDIMM memory capacity of 3.07 TB. The server supports RAID levels 0, 1, 5, and 10 for data redundancy and performance. It includes an on-board graphics card, the Aspeed AST2500, with 64 MB of memory. For networking, the server is equipped with Gigabit Ethernet and operates at data rates of 10, 100, and 1000 Mbit/s, utilizing the Intel I350-BT2 LAN controller.

Processor

Built-in processor
Built-in processor
Yes
show more


Motherboard chipset
Motherboard chipset
Intel® C621
show more


Processor socket
Processor socket
LGA 3647 (Socket P)
show more


Processor family
Processor family
Intel® Xeon® Scalable
show more


Number of processors supported
Number of processors supported
2
show more


System bus rate
System bus rate
10.4 GT/s
show more

Memory

Number of DIMM slots
Number of DIMM slots
24
show more


Supported memory types
Supported memory types
DDR4-SDRAM
show more


Supported DIMM module capacities
4GB, 8GB, 16GB, 32GB, 64GB, 128GB
show more


Maximum RDIMM memory
3.07 TB
show more


Supported RDIMM clock speeds
2400,2666,2933 MHz
show more

Storage

Number of storage drives supported
Number of storage drives supported
12
show more


Hot-swap HDD bays
Hot-swap HDD bays
Yes
show more


RAID levels
RAID levels
0, 1, 5, 10
show more

Graphics

On-board graphics card model
On-board graphics card model
Aspeed AST2500
show more


On-board graphics card memory
64 MB
show more

Network

Ethernet LAN
Ethernet LAN
Yes
show more


Ethernet interface type
Gigabit Ethernet
show more


Ethernet LAN data rates
Ethernet LAN data rates
10,100,1000 Mbit/s
show more


LAN controller
Intel I350-BT2
show more

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
show more


Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
2
show more


VGA (D-Sub) ports quantity
VGA (D-Sub) ports quantity
1
show more


Number of SATA III connectors
Number of SATA III connectors
10
show more

Expansion slots

PCI Express x8 (Gen 3.x) slots
PCI Express x8 (Gen 3.x) slots
1
show more


PCI Express x16 (Gen 3.x) slots
PCI Express x16 (Gen 3.x) slots
2
show more

Logistics data

Harmonized System (HS) code
84714100
show more

Design

Chassis type
Chassis type
Rack (1U)
show more


Product colour
Product colour
Stainless steel
show more


LED indicators
Yes
show more


Rack rails
Yes
show more


Heat sink included
Yes
show more


Redundant fans support
Yes
show more

Power

Power supply
Power supply
800 W
show more


Redundant power supply (RPS) support
Redundant power supply (RPS) support
Yes
show more


AC input frequency
47 – 63 Hz
show more


Input current
9.4 A
show more

Operational conditions

Storage relative humidity (H-H)
20 – 90%
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 60 °C
show more


Operating temperature (T-T)
Operating temperature (T-T)
10 – 35 °C
show more

Weight & dimensions

Weight
Weight
16.8 kg
show more


Height
Height
44 mm
show more


Depth
Depth
686 mm
show more


Width
Width
444 mm
show more

Packaging data

Package weight
Package weight
18.4 kg
show more
