UPS 93PS 10kVA 3/3 93PS-10(10)-1x9Ah-MBS

The Eaton 93PS is a Double-conversion (Online) UPS designed to deliver a reliable power supply with an output power capacity of 10 kVA and a total output power of 10,000 watts. It utilizes Sealed Lead Acid (VRLA) battery technology, with a battery capacity of 9 Ah and a battery voltage of 12 V. This UPS comes in a tower form factor and is available in black. It features an LCD display for easy monitoring and management. The Eaton 93PS adheres to several compliance standards, including RoHS, and is certified under the WEEE directive. Its safety standards are compliant with IEC 62040-1, IEC 62040-2, and IEC 62040-3.

Features

UPS topology
UPS topology
Double-conversion (Online)
show more


Output power capacity
Output power capacity
10 kVA
show more


Output power
Output power
10000 W
show more


Input operation voltage (min)
Input operation voltage (min)
220 V
show more


Input operation voltage (max)
Input operation voltage (max)
415 V
show more


Input frequency
Input frequency
50/60 Hz
show more


Output operation voltage (min)
Output operation voltage (min)
220 V
show more


Output operation voltage (max)
Output operation voltage (max)
415 V
show more


Output frequency
50/60 Hz
show more


Maximum current
Maximum current
13 A
show more


Number of input phases
3
show more


Number of output phases
3
show more


Efficiency (On-line mode)
96%
show more


Input power factor
0.99
show more


Output power factor
1
show more


Emergency Power Off (EPO)
Yes
show more


Overload capacity (10 minutes)
110%
show more


Overload capacity (1 minute)
125%
show more


Overload capacity (10 seconds)
150%
show more


Total Harmonic Distortion (THD) (linear load)
1.5%
show more


Total Harmonic Distortion (THD) (non-linear load)
3.5%
show more


Noise level
Noise level
54 dB
show more


Power protection features
Power protection features
Overload
show more

Ports & interfaces

USB port
USB port
Yes
show more


RS-232 ports
RS-232 ports
1
show more


Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
1
show more

Battery

Battery technology
Battery technology
Sealed Lead Acid (VRLA)
show more


Battery capacity
Battery capacity
9 Ah
show more


Battery voltage
Battery voltage
12 V
show more


Number of battery cells
192
show more


Battery life (max)
5 year(s)
show more


Hot-swap battery
Yes
show more

Design

Form factor
Form factor
Tower
show more


Product colour
Product colour
Black
show more


Display type
Display type
LCD
show more


LED indicators
Yes
show more


International Protection (IP) code
International Protection (IP) code
IP20
show more

Operational conditions

Operating altitude
0 – 2000 m
show more

Safety regulation & standards

Safety
Safety
IEC 62040-1, IEC 62040-2, IEC 62040-3
show more

Certificates

Compliance certificates
RoHS
show more


Certification
WEEE
show more

Weight & dimensions

Width
Width
335 mm
show more


Depth
Depth
750 mm
show more


Height
Height
950 mm
show more
