The AFi-Cable-USB is a high-quality braided power and data cable designed to enhance your connectivity experience. This versatile cable features a dual function with its double-sided charge display, allowing you to see the charging status from either end. Whether at home or in the office, this cable is crafted to meet your daily connectivity needs.
It is available in different lengths of 0.3, 2, 4.5, and 7 meters (1, 6.6, 13.1, and 23 feet), with weights ranging from 16 to 560 grams (0.6 to 19.8 ounces). The jacket diameter varies slightly based on length, providing a comfortable fit in any setting while maintaining durability with its PP and PET braiding. The cable comes in sleek black and cool gray colors, adding a stylish touch.
Equipped with a USB Type-C connector, this cable is compatible with a wide range of devices. It supports a maximum power output of 100W PD, making it suitable for charging even high-power equipment. The cable offers a maximum data transfer rate of 480 Mbps for shorter lengths, though the 4.5-meter and 7-meter versions are optimized for charging only.
Built to endure various environmental conditions, this cable functions efficiently within a temperature range of -20 to 60° C (-4 to 140° F) and in humidity levels from 10 to 90% non-condensing. It features robust shielding through a shielded twisted pair (STP) configuration and a stranded tinned copper conductor, ensuring reliability and performance.
| Specifications | |
|---|---|
| Cable length | 0.3/2/4.5/7 m (1/6.6/13.1/23 ft) |
| Cable weight | 16/76/217/560 g (0.6/2.7/7.6/19.8 oz) |
| Jacket diameter | 0.3/2/4.5 m: 4.4 mm (0.17") 7 m: 5.3 mm (0.2") |
| Jacket color | Black, cool gray |
| Cable jacket material | PP & PET braiding |
| Bend radius (min.) | 0.3/2 m: 15 mm (0.6") 4.5 m: 20 mm (0.8") 7 m: 27 mm (1.1") |
| Cable connector type | USB Type-C |
| Shielding type | Shielded twisted pair (STP) |
| Conductor wire gauge | 0.3/2/4.5 m: (3) 24AWG (2) 30AWG (2) 32AWG 7 m: |
| Conductor type | Stranded tinned copper |
| Display | Double-sided charge display |
| Max. power output | 100W PD |
| Max. data rate | 0.3/2 m: 480 Mbps 4.5/7 m: n/a – charging only |
| Ambient operating temperature | -20 to 60°C (-4 to 140°F) |
| Ambient operating humidity | 10 to 90% noncondensing |
