Ubiquiti Networks AG-HP-5G27 Network Antenna 27 dBi

The AG-HP-5G27 is part of the Ubiquiti AirGrid M series, providing an efficient solution for high-performance connectivity. Operating on the 5 GHz band, it delivers over 100 Mbps of bandwidth and offers a range exceeding 30 km.

This radio system is equipped with a 400 MHz Atheros MIPS 24KC processor, 32 MB of internal memory, and 8 MB of flash memory. The antenna features a maximum gain of 27 dBi, ensuring strong and reliable signals.

The AG-HP-5G27 is compatible with the AirMax protocol, allowing for optimal use of available bandwidth. It is versatile, suited for creating wireless bridges or serving as a client device for long-distance applications.

Built for durability, it uses robust components and innovative solutions to perform smoothly under harsh conditions. The device can operate at temperatures ranging from -30 to 75 degrees Celsius.

Key features include:
– Operation in the 5 GHz band
– Over 100 Mbps of bandwidth
– A range of over 30 km
– A 27 dBi antenna
– Dimensions of 620 x 460 mm

Installation of the AG-HP-5G27 from the AirGrid M series is straightforward, not requiring any specialized tools.

A comparison with other models in the series shows:

– Frequency:
– AG-HP-2G16: 2.4 GHz
– AG-HP-2G20: 2.4 GHz
– AG-HP-5G23: 5 GHz
– AG-HP-5G27: 5 GHz

– Throughput for all models is over 100 Mbps.

– Range:
– AG-HP-2G16: Over 10 km
– AG-HP-2G20: Over 20 km
– AG-HP-5G23: Over 25 km
– AG-HP-5G27: Over 30 km

For more in-depth information, refer to the manufacturer's documentation and manual.
