QuMax Omni for Robustel LG5100 LoRa, 2x Antenna LTE + 1x LoRa

The QuWireless Antenna QuMax Omni is designed for the Robustel LG5100 LoRa. It offers a maximum antenna gain level of 3 dBi and operates within a frequency band of 0.694 to 2.7 GHz. The antenna features an impedance of 50 ohms and is an omni-directional type. It comes with a female connector and is white in color. The antenna's dimensions are 272 mm in width, 96 mm in depth, and 276 mm in height. Each pack contains one piece.

Performance

Frequency band
Frequency band
0.694 – 2.7 GHz
show more


Impedance
Impedance
50 Ω
show more


Vertical beam width
25°
show more


Horizontal beam width
360°
show more


Antenna gain level (max)
Antenna gain level (max)
3 dBi
show more

Features

Antenna type
Antenna type
Omni-directional antenna
show more


Connector gender
Connector gender
Female
show more


Product colour
Product colour
White
show more


Housing material
Housing material
Acrylonitrile butadiene styrene (ABS), Aluminium, Polytetrafluoroethylene (PTFE)
show more


International Protection (IP) code
International Protection (IP) code
IP67
show more


Front to back ratio
17 dB
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
-40 – 75 °C
show more

Weight & dimensions

Width
Width
272 mm
show more


Depth
Depth
96 mm
show more


Height
Height
276 mm
show more


Weight
Weight
1.8 kg
show more

Packaging content

Quantity per pack
1 pc(s)
show more
