APC NetShelter Rack PDU Advanced Switched 11.5kW 3PH 415V 20A 520P6 42 Outlet

The APC NetShelter Rack PDU Advanced is a switched, three-phase power distribution unit designed for high-efficiency performance. It supports a capacity of 11 kW at 400V and 16A or 11.5 kW at 415V and 20A. This unit features 42 AC outlets with various outlet types including C13, C15, C19, and C21 couplers, and uses an IEC 60309 power plug. It includes LED indicators for activity, network status, and power, and has a cable length of 1.8 meters.

Security features encompass 128-bit, 192-bit, and 256-bit AES encryption, along with DES, MD5, SNMP, SNMPv2, and SNMPv3 protocols. The PDU offers comprehensive monitoring capabilities, allowing measurement of current, humidity, power, temperature, and voltage. It also provides outlet controls such as lock-out, recycle, turn off, and turn on functions. Furthermore, the firmware can be upgraded via network or USB.

The nominal input voltage is 400V and it can handle a maximum current of 16A, operating at an AC input frequency range of 50 to 60 Hz.

Design

PDU types
PDU types
Switched
show more


Type
Type
Three-phase
show more


Form factor
Form factor
Rackmount
show more


Rack capacity
Rack capacity
0U
show more


Mounting
Mounting
Vertical
show more


Product colour
Product colour
Black
show more


Display
Display
LCD
show more


On/off switch
On/off switch
Yes
show more


Regulatory Approvals
CE, CSA C22.2 No 62368-1, EN 62368-1, FCC part 15 subpart B, UKCA, UL 62368-1
show more

Ports & interfaces

AC outlets quantity
AC outlets quantity
42 AC outlet(s)
show more


Power plug
Power plug
IEC 60309
show more


AC outlet types
AC outlet types
C13 coupler, C15 coupler, C19 coupler, C21 coupler
show more


Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
2
show more


USB ports quantity
1
show more

Features

Daisy chain
Yes
show more


Reset button
Yes
show more


LED indicators
Activity, Network, Power
show more


Colour-coded outlets
Yes
show more


Cable length
Cable length
1.8 m
show more


Security algorithms
Security algorithms
128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SNMP, SNMPv2, SNMPv3
show more


Password protection
Password protection
Yes
show more


Compatible products
Compatible products
Compatible with most NetShelter SX
enclosures and third-party racks
show more

Management features

Monitoring
Current, Humidity, Power, Temperature, Voltage
show more


Outlet control
Lock-out, Recycle, Turn off, Turn on
show more


Firmware upgradeable via
Network, USB
show more


Firmware upgradeable
Yes
show more

Power

Nominal input voltage
Nominal input voltage
400 V
show more


AC input frequency
50 – 60 Hz
show more


Maximum current
Maximum current
16 A
show more


Nominal output voltage
Nominal output voltage
230 V
show more


Output voltage
230 V
show more


Load capacity
11500 VA
show more


Number of phases
3
show more


Maximum total current draw per phase
16 A
show more


Surge protection
Yes
show more


Power protection features
Power protection features
Overload
show more


Maximum power
Maximum power
11500 W
show more

Certificates

Compliance certificates
RoHS
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
-5 – 60 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-25 – 65 °C
show more


Storage relative humidity (H-H)
5 – 95%
show more


Operating relative humidity (H-H)
5 – 95%
show more


Operating altitude
0 – 3048 m
show more


Non-operating altitude
0 – 15240 m
show more


Operating temperature (T-T)
23 – 140 °F
show more

Weight & dimensions

Width
Width
56 mm
show more


Depth
Depth
75 mm
show more


Height
Height
1490 mm
show more


Weight
Weight
7.2 kg
show more

Packaging data

Package weight
Package weight
9.2 kg
show more


Package width
Package width
208 mm
show more


Package depth
Package depth
116 mm
show more


Package height
Package height
1720 mm
show more

Logistics data

Total carbon footprint (kg of CO2e)
Total carbon footprint (kg of CO2e)
2894.37
show more
