QuMax Omni with PoE Splitter for Robustel R3000, 2x Antenna LTE + 1x Wi-Fi Dual Band + GPS + PoE Splitter

The QuWireless AR3000MO is an omni-directional antenna with a maximum antenna gain level of 7.5 dBi. It operates across frequency bands ranging from 694 – 2700 MHz, as well as 2.4 GHz, 5 GHz, and 7 GHz. For the 2.4 GHz band, the antenna gain is 6 dBi. It features a PoE/LAN antenna connector type and supports vertical polarization. The device dimensions are a width of 272 mm, a depth of 276 mm, and a height of 96 mm.

Performance

Frequency band
Frequency band
694 – 2700/2.4/5/7 GHz
show more


Antenna gain (5 GHz)
7.5 dBi
show more


Antenna gain (2.4 GHz)
6 dBi
show more


Impedance
Impedance
50 Ω
show more


Horizontal beam width
360°
show more


Vertical beam width
25°
show more


Antenna gain level (max)
Antenna gain level (max)
7.5 dBi
show more

Features

Antenna type
Antenna type
Omni-directional antenna
show more


Antenna connector type
Antenna connector type
PoE/LAN
show more


Polarization
Vertical polarization
show more


Voltage Standing Wave Ratio (VSWR)
2.50
show more


Product colour
Product colour
White
show more


Housing material
Housing material
Aluminium, Polytetrafluoroethylene (PTFE)
show more


International Protection (IP) code
International Protection (IP) code
IP67
show more


Mounting
Mounting
Ceiling/wall
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
-40 – 75 °C
show more

Weight & dimensions

Width
Width
272 mm
show more


Depth
Depth
276 mm
show more


Height
Height
96 mm
show more


Weight
Weight
1.8 kg
show more
