TP-Link Archer C6 V3.20 Dual Band Wireless Router

The TP-Link Archer C6 V3.20 is a high-performance dual-band wireless router tailored for exceptional internet connectivity, suitable for both home and small office environments. It operates on both 2.4 GHz and 5 GHz frequencies, supporting the Wi-Fi 5 (802.11ac) standard with a maximum WLAN data transfer rate of 1200 Mbit/s. This router uses advanced technology to ensure fast and efficient data transmission, making it perfect for activities like streaming, gaming, and browsing.

The router features a WAN connection via an RJ-45 port and includes four Gigabit Ethernet LAN ports that support data rates of 10, 100, and 1000 Mbit/s through 10/100/1000Base-T(X) cabling technology. This enables users to enjoy high-speed wired connections, enhancing overall network performance. The Archer C6 V3.20 prioritizes security with robust protocols such as WEP, WPA, WPA-PSK, and WPA2, along with a DoS and SPI firewall to protect against potential threats.

Designed with a sleek black exterior for tabletop use, the TP-Link Archer C6 V3.20 is easy to monitor due to its LED indicators for LAN, power, status, WLAN, and WPS. With its combination of advanced features and strong security measures, the Archer C6 is a reliable choice for users who seek a dependable networking solution that meets the demands of modern internet usage.

WAN connection

Ethernet WAN
Yes
show more


SIM card slot
SIM card slot
No
show more


3G/4G USB modem compatibility
No
show more


WAN connection type
RJ-45
show more

Wireless LAN features

Wi-Fi band
Wi-Fi band
Dual-band (2.4 GHz / 5 GHz)
show more


Top Wi-Fi standard
Top Wi-Fi standard
Wi-Fi 5 (802.11ac)
show more


WLAN data transfer rate (max)
1200 Mbit/s
show more


Wi-Fi standards
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 5 (802.11ac)
show more


WLAN data transfer rate (first band)
300 Mbit/s
show more


WLAN data transfer rate (second band)
867 Mbit/s
show more

Network

Ethernet LAN
Ethernet LAN
Yes
show more


Ethernet LAN interface type
Ethernet LAN interface type
Gigabit Ethernet
show more


Ethernet LAN data rates
Ethernet LAN data rates
10,100,1000 Mbit/s
show more


Cabling technology
Cabling technology
10/100/1000Base-T(X)
show more


Networking standards
Networking standards
IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
show more


Port triggering
Yes
show more


Port forwarding
Yes
show more


Dynamic DNS (DDNS)
Yes
show more


VPN server
PPTP VPN, OpenVPN
show more


Receiver sensitivity
11a 6Mbps:-93dBm;11a 54Mbps:-78dBm;
11ac HT20 mcs8:-69dBm;11ac HT40 mcs9:-65dBm;
11ac HT80 mcs9:-62dBm;
2.4GHz:
11g 54Mbps:-78dBm;
11n HT20 mcs7:-74dBm;
11n HT40 mcs7:-71dbm;
show more

Mobile network

3G
3G
No
show more


4G
4G
No
show more


5G
No
show more

Ports & interfaces

Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
4
show more


USB port
USB port
No
show more


Memory card slot(s)
Memory card slot(s)
No
show more

Management features

Quality of Service (QoS) support
Yes
show more


Reset button
Yes
show more


WPS push button
Yes
show more


MU-MIMO technology
Yes
show more

Security

Security algorithms
Security algorithms
WEP, WPA, WPA-PSK, WPA2
show more


Firewall security
Firewall security
DoS, SPI Firewall, IP and MAC Address Binding
show more


DMZ support
Yes
show more

Protocols

DHCP client
DHCP client
Yes
show more


DHCP server
DHCP server
Yes
show more


Universal Plug and Play (UPnP)
Yes
show more

Design

Product colour
Product colour
Black
show more


Wall mountable
Wall mountable
Yes
show more


LED indicators
LAN, Power, Status, WLAN, WPS
show more


On/off switch
On/off switch
Yes
show more


Product type
Product type
Tabletop router
show more

Certificates

Certification
FCC, CE, RoHS
show more

Antenna

Antenna design
External
show more


Transmit power
20 – 23 dBmW
show more

Features

Built-in processor
Built-in processor
Yes
show more


Processor cores
Processor cores
2
show more

Power

Power source type
Power source type
DC
show more


Output voltage
12 V
show more


Output current
1 A
show more

Operational conditions

Storage relative humidity (H-H)
5 – 90%
show more


Operating relative humidity (H-H)
10 – 90%
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 70 °C
show more


Operating temperature (T-T)
Operating temperature (T-T)
0 – 40 °C
show more

Weight & dimensions

Height
Height
32 mm
show more


Depth
Depth
117 mm
show more


Width
Width
215 mm
show more
