EPSON DFX-9000 dot matrix printer

The Epson DFX-9000 is a high-performance printer designed for efficient printing needs. It boasts a maximum print speed of 1550 characters per second (cps) and a maximum resolution of 240 x 144 dots per inch (DPI). In draft mode, the printer can achieve speeds of up to 1320 cps. It supports a maximum print size of A4 (210 x 297 mm) and is compatible with media types such as labels. The printer features a buffer size of 128 KB and operates at a sound pressure level of 58 decibels during printing. It supports page description languages including ESC P and PPDS. Standard connectivity is provided through parallel, RS-232, and USB 2.0 interfaces, with optional Ethernet connectivity available. This model uses a 9-pin print head that operates bidirectionally and has an impressive print head life of 200 million characters.

Printing

Maximum resolution
Maximum resolution
240 x 144 DPI
show more


Maximum printing width (columns)
Maximum printing width (columns)
136
show more


Colour
Colour
No
show more


Maximum print speed
Maximum print speed
1550 cps
show more


Maximum print speed (draft)
1320 cps
show more


Maximum print speed (LQ)
330 cps
show more


Character pitch
10,12 cpi
show more


Maximum number of copies
10 copies
show more


Built-in barcodes
Code 39, POSTNET, UPC-A, UPC-E
show more

Paper handling

Maximum print size
Maximum print size
A4 (210 x 297 mm)
show more


Paper tray media types
Labels
show more

Features

Buffer size
Buffer size
128 KB
show more


Sound pressure level (printing)
58 dB
show more


Page description languages
ESC P, PPDS
show more


Country of origin
Country of origin
Japan
show more

Ports & interfaces

Standard interfaces
Standard interfaces
Parallel, RS-232, USB 2.0
show more


Optional connectivity
Ethernet
show more

Endurance

Print head
Print head
9-pin
show more


Print direction
Bidirectional
show more


Print head life
200 million characters
show more


Ribbon life (black, draft)
15 million characters
show more


Mean time between failures (MTBF)
Mean time between failures (MTBF)
20000 h
show more

Power

Power consumption (standby)
Power consumption (standby)
75 W
show more


Power consumption (typical)
Power consumption (typical)
185 W
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
5 – 35 °C
show more


Operating relative humidity (H-H)
10 – 80%
show more

System requirements

Bundled software
Bundled software
Epson Status Monitor
show more


Windows operating systems supported
Windows operating systems supported
Windows 2000, Windows 7, Windows 8, Windows 98, Windows XP
show more

Weight & dimensions

Width
Width
700 mm
show more


Depth
Depth
378 mm
show more


Height
Height
363 mm
show more


Weight
Weight
34 kg
show more

Packaging data

Quantity per pack
1 pc(s)
show more


Package width
Package width
485 mm
show more


Package depth
Package depth
840 mm
show more


Package height
Package height
505 mm
show more


Package weight
Package weight
35.5 g
show more

Other features

Needles
36 (4 x 9)
show more


Print technology
Print technology
Dot matrix
show more


Connectivity technology
Connectivity technology
Wired
show more

Logistics data

Pallet length (UK)
120 cm
show more


Pallet width (UK)
100 cm
show more


Pallet height (UK)
2.1 m
show more


Harmonized System (HS) code
84433210
show more


Products per pallet (UK)
8 pc(s)
show more


Products per pallet layer (UK)
2 pc(s)
show more


Pallet gross width
120 cm
show more


Pallet gross height
100 cm
show more


Products per pallet layer
1 pc(s)
show more


Products per pallet
Products per pallet
4 pc(s)
show more
