TP-Link CPE510 5 GHz 300 Mbps 13 dBi Outdoor CPE

The TP-Link CPE510 is a high-performance outdoor wireless device that operates on a 5 GHz frequency, providing a maximum data transfer rate of 300 Mbps. This capability ensures fast and efficient wireless connectivity, making it ideal for various outdoor applications, such as extending Wi-Fi coverage in large areas or connecting remote locations. Featuring a high-gain 13 dBi antenna, the CPE510 significantly boosts signal strength and extends coverage, while ensuring reliable connectivity even in challenging environments.

The TP-Link CPE510 comes equipped with advanced security features, supporting multiple encryption algorithms like WPA2 and WPA2-PSK, which protect your network from unauthorized access. The device uses TDMA management protocols to optimize data transmission and reduce latency, offering superior performance compared to many competitors in the market. It also adheres to IEEE 802.11a and IEEE 802.11n standards, ensuring compatibility with a wide range of wireless equipment.

Managing the TP-Link CPE510 is convenient with the Pharos Control platform, a centralized management application that simplifies setup and maintenance. An Ethernet (RJ-45) port facilitates the WAN connection, offering reliable wired connectivity to enhance network stability. With its robust features and versatile configurations, the CPE510 is an excellent choice for users seeking to establish a robust outdoor wireless network.

Features

Maximum data transfer rate
Maximum data transfer rate
300 Mbit/s
show more


Wi-Fi data rate (max)
300 Mbit/s
show more


Ethernet LAN data rates
Ethernet LAN data rates
10,100 Mbit/s
show more


Frequency band
Frequency band
5.15 – 5.85 GHz
show more


Bandwidth
5 GHz
show more


Networking standards
Networking standards
IEEE 802.11a, IEEE 802.11n
show more


Maximum outdoor range
Maximum outdoor range
15000 m
show more


Receiver sensitivity
802.11a:
54M: -75dBm, 48M: -76dBm, 36M: -83dBm, 6-24M: -95dBm

802.11n:
MCS15: -73dBm, MCS14: -74dBm, MCS13: -76dBm,
MCS12: -80dBm, MCS11: -83dBm, MCS10: -88dBm,
MCS9: -90dBm, MCS8: -93dBm, MCS7: -73dBm,
MCS6: -74dBm, MCS5: -76dBm, MCS4: -80dBm,
MCS3: -83dBm, MCS2: -88dBm, MCS1: -90dBm, MCS0: -93dBm

show more

Security

Security algorithms
Security algorithms
64-bit WEP, 128-bit WEP, 152-bit WEP, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK
show more


MAC address filtering
MAC address filtering
Yes
show more

Protocols

Management protocols
TDMA
show more

Management features

Web-based management
Web-based management
Yes
show more


Management platform
Pharos Control
show more

Ports & interfaces

Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
1
show more


WAN connection
WAN connection
Ethernet (RJ-45)
show more

Power

Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
show more


AC input frequency
50 – 60 Hz
show more


AC input voltage
AC input voltage
100 – 240 V
show more


Input current
0.8 A
show more


Power consumption (typical)
Power consumption (typical)
13 W
show more

Design

Product colour
Product colour
White
show more


Reset button
Yes
show more


LED indicators
Yes
show more


Internal
Internal
No
show more

Antenna

Antenna features
Integrated antenna
show more


Antennas quantity
1
show more


Antenna gain level (max)
Antenna gain level (max)
13 dBi
show more

Performance

Built-in processor
Built-in processor
Yes
show more


Internal memory
Internal memory
64 MB
show more


Flash memory
8 MB
show more


Compatible operating systems
Compatible operating systems
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
show more

Certificates

Certification
FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark
RoHS
show more

Weight & dimensions

Width
Width
224 mm
show more


Depth
Depth
75 mm
show more


Height
Height
60 mm
show more

Packaging content

Cables included
AC
show more

Operational conditions

Operating relative humidity (H-H)
10 – 90%
show more


Operating temperature (T-T)
Operating temperature (T-T)
-30 – 70 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 70 °C
show more


Storage relative humidity (H-H)
5 – 95%
show more

Logistics data

Harmonized System (HS) code
85176990
