D-Link DGS-1005D/E Network Switch Unmanaged L2 Gigabit Ethernet (10/100/1000) Black

The D-Link DGS-1005D/E is an unmanaged switch designed for seamless connectivity and efficient networking. It operates at Layer 2, offering basic switching capabilities with its five RJ-45 Ethernet ports that support Gigabit Ethernet speeds of 10/100/1000 Mbps. This switch supports full duplex mode, allowing for simultaneous two-way data transmission that enhances network performance.

The device features a MAC address table with a capacity of 2000 entries, ensuring robust network management and device identification. With a switching capacity of 10 Gigabits per second, it efficiently handles high data traffic, making it ideal for various networking needs.

Conforming to key networking standards such as IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, and IEEE 802.3u, this switch ensures compatibility and reliability across different network environments. It operates with a DC input voltage of 5 volts, further underlining its efficient power usage.

Management features

Switch type
Switch type
Unmanaged
show more


Switch layer
Switch layer
L2
show more


Quality of Service (QoS) support
Yes
show more

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
Basic switching RJ-45 Ethernet ports quantity
5
show more


Basic switching RJ-45 Ethernet ports type
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
show more

Network

Networking standards
Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
show more


10G support
10G support
No
show more


Full duplex
Full duplex
Yes
show more


MAC address auto-learning supported
Yes
show more


Ethernet LAN data rates
Ethernet LAN data rates
10,100,1000 Mbit/s
show more


Auto MDI/MDI-X
Auto MDI/MDI-X
Yes
show more

Data transmission

Switching capacity
Switching capacity
10 Gbit/s
show more


MAC address table
MAC address table
2000 entries
show more


Store-and-forward
Yes
show more


Jumbo frames support
Yes
show more


Jumbo frames
9216
show more


Packet forwarding rate (10 Mbps)
14880 pps
show more


Packet forwarding rate (100 Mbps)
148800 pps
show more


Packet forwarding rate (1 Gbps)
1488000 pps
show more


Packet buffer memory
0.128 MB
show more

Design

Rack mounting
Rack mounting
No
show more


Product colour
Product colour
Black
show more


Housing material
Housing material
Plastic
show more


LED indicators
Yes
show more

Performance

Mean time between failures (MTBF)
Mean time between failures (MTBF)
1142330 h
show more

Power

DC input voltage
5 V
show more


Input current
1 A
show more


Power consumption (max)
Power consumption (max)
2.01 W
show more

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
0 – 40 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-10 – 70 °C
show more


Operating relative humidity (H-H)
10 – 90%
show more


Storage relative humidity (H-H)
5 – 90%
show more

Weight & dimensions

Width
Width
111 mm
show more


Depth
Depth
75 mm
show more


Height
Height
30 mm
show more


Weight
Weight
80 g
show more

Packaging content

Manual
Yes
show more

Logistics data

Harmonized System (HS) code
85176990
