D-Link DGS-1026MP Network Switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black, Grey

The D-Link DGS-1026MP is an unmanaged switch designed for efficient network management. It features 24 Gigabit Ethernet (10/100/1000) RJ-45 ports, offering ample connectivity options. The switch supports a MAC address table with up to 8192 entries and boasts a switching capacity of 52 Gbit/s. It adheres to several networking standards, including IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, and IEEE 802.3x. This model also supports Power over Ethernet (PoE) and can be mounted in a rack for convenient installation.

Management features

Switch type
Switch type
Unmanaged
show more

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
Basic switching RJ-45 Ethernet ports quantity
24
show more


Basic switching RJ-45 Ethernet ports type
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
show more


Combo SFP ports quantity
2
show more

Network

Networking standards
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
show more


10G support
10G support
No
show more


Auto MDI/MDI-X
Auto MDI/MDI-X
Yes
show more

Data transmission

Switching capacity
Switching capacity
52 Gbit/s
show more


Throughput
38.69 Mpps
show more


Forwarding rate
38.69 Mpps
show more


MAC address table
MAC address table
8192 entries
show more


Store-and-forward
Yes
show more


Packet buffer memory
0.512 MB
show more

Design

Rack mounting
Rack mounting
Yes
show more


Product colour
Product colour
Black, Grey
show more


LED indicators
Activity, Link, PoE, Power, Power fail, Speed
show more


Number of fans
Number of fans
2 fan(s)
show more


Safety
Safety
UL/CSA 60950-1, EN 60950-1, IEC 60950-1
show more

Performance

Buffer size
Buffer size
512 KB
show more


Mean time between failures (MTBF)
Mean time between failures (MTBF)
205975 h
show more

Power

Power source
Power source
AC
show more


Power supply included
Power supply included
Yes
show more


AC input voltage
AC input voltage
100 – 240 V
show more


AC input frequency
50/60 Hz
show more


Power consumption (max)
Power consumption (max)
444.1 W
show more

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
show more


Power over Ethernet plus (PoE+) ports quantity
24
show more


Power over Ethernet (PoE) power per port
30 W
show more


Total Power over Ethernet (PoE) budget
370 W
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
0 – 50 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 70 °C
show more


Operating relative humidity (H-H)
10 – 90%
show more


Storage relative humidity (H-H)
5 – 90%
show more


Heat dissipation
Heat dissipation
1515 BTU/h
show more

Weight & dimensions

Width
Width
440 mm
show more


Depth
Depth
250.4 mm
show more


Height
Height
44 mm
show more


Weight
Weight
3.1 kg
show more

Packaging data

Package width
Package width
388 mm
show more


Package depth
Package depth
506 mm
show more


Package height
Package height
90 mm
show more


Package weight
Package weight
3.7 kg
show more

Technical details

Pallet gross weight (sea)
369.8 kg
show more


Pallet height (air)
136.5 cm
show more


Pallet gross width
120 cm
show more


Master (outer) cases per pallet (sea)
40 pc(s)
show more


Products per pallet (sea)
80 pc(s)
show more


Shipping (inner) case gross weight
8.79 kg
show more


Pallet height (sea)
177.5 cm
show more


Pallet gross length
110 cm
show more


Products per pallet (air)
60 pc(s)
show more


Shipping (inner) case length
52 cm
show more


Shipping (inner) case width
20.5 cm
show more


Shipping (inner) case net weight
8.39 kg
show more


Products per shipping (inner) case
2 pc(s)
show more


Master (outer) cases per pallet (air)
30 pc(s)
show more


Pallet gross weight (air)
281.8 kg
show more


Shipping (inner) case height
41 cm
show more

Certificates

Compliance certificates
BSMI, CCC, CE, Federal Communications Commission (FCC), RCM, RoHS, VCCI
show more


Certification
FCC Class A
CE
CCC
RoHS
VCCI
BSMI
RCM
show more

Logistics data

Harmonized System (HS) code
85176990
show more
