D-Link DGS-1510 Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet PoE Black

The D-Link DGS-1510 is a managed switch operating at Layer 3. It features 48 Gigabit Ethernet RJ-45 ports, capable of speeds up to 10/100/1000 Mbps, allowing for full duplex communication. The switch supports a MAC address table size of 16,000 entries and offers a switching capacity of 128 Gbit/s. It adheres to networking standards such as IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, and IEEE 802.3x. Additionally, it supports Power over Ethernet (PoE) and is suitable for rack mounting.

Management features

Switch type
Switch type
Managed
show more


Switch layer
Switch layer
L3
show more


Quality of Service (QoS) support
Yes
show more


Web-based management
Web-based management
Yes
show more


ARP inspection
Yes
show more


Traffic classification
Yes
show more

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
Basic switching RJ-45 Ethernet ports quantity
48
show more


Basic switching RJ-45 Ethernet ports type
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
show more


SFP+ module slots quantity
4
show more

Network

Networking standards
Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
show more


10G support
10G support
Yes
show more


Cable types supported
Cat5, Cat5e
show more


Full duplex
Full duplex
Yes
show more


Auto MDI/MDI-X
Auto MDI/MDI-X
Yes
show more

Data transmission

Switching capacity
Switching capacity
128 Gbit/s
show more


Throughput
95.24 Mpps
show more


MAC address table
MAC address table
16000 entries
show more


Number of IP interfaces
16
show more


Jumbo frames support
Yes
show more


Jumbo frames
9216
show more

Multicast features

Multicast support
Yes
show more


Multicast MAC address table
512 entries
show more

Design

Rack mounting
Rack mounting
Yes
show more


Stackable
Stackable
Yes
show more


Product colour
Product colour
Black
show more


Reset button
Yes
show more


LED indicators
Activity, Link, PoE, Speed
show more


Number of fans
Number of fans
3 fan(s)
show more

Performance

Noise level
Noise level
56.9 dB
show more

Power

Power supply included
Power supply included
Yes
show more


AC input voltage
AC input voltage
100 – 240 V
show more


AC input frequency
50 – 60 Hz
show more


Power consumption (max)
Power consumption (max)
486.9 W
show more

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
-5 – 50 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-20 – 70 °C
show more


Operating relative humidity (H-H)
0 – 95%
show more


Storage relative humidity (H-H)
0 – 95%
show more


Heat dissipation
Heat dissipation
138.787 BTU/h
show more

Weight & dimensions

Width
Width
440 mm
show more


Depth
Depth
308 mm
show more


Height
Height
44 mm
show more


Weight
Weight
5.41 kg
show more

Packaging data

Package width
Package width
475 mm
show more


Package depth
Package depth
520 mm
show more


Package height
Package height
110 mm
show more


Package weight
Package weight
7.26 kg
show more

Technical details

Pallet gross weight (sea)
400.7 kg
show more


Pallet height (air)
166 cm
show more


Pallet gross width
120 cm
show more


Master (outer) cases per pallet (sea)
24 pc(s)
show more


Products per pallet (sea)
48 pc(s)
show more


Shipping (inner) case gross weight
16.1 kg
show more


Pallet height (sea)
166 cm
show more


Pallet gross length
110 cm
show more


Products per pallet (air)
48 pc(s)
show more


Shipping (inner) case length
55.5 cm
show more


Shipping (inner) case width
27.3 cm
show more


Shipping (inner) case net weight
14.5 kg
show more


Products per shipping (inner) case
2 pc(s)
show more


Master (outer) cases per pallet (air)
24 pc(s)
show more


Pallet gross weight (air)
400.7 kg
show more


Shipping (inner) case height
50.7 cm
show more

Certificates

Certification
CE
FCC
C-Tick
VCCI
BSMI
cUL
CB
show more

Logistics data

Harmonized System (HS) code
85176990
show more
