D-Link DIS-100G-5W Unmanaged L2 Gigabit Ethernet (10/100/1000) Black

The D-Link DIS-100G-5W is an unmanaged switch designed for efficient network management. It operates on layer 2 of the network architecture, providing fundamental switching capabilities. The switch features five Gigabit Ethernet RJ-45 ports, supporting speeds of 10/100/1000 Mbps, ensuring full duplex communication. It has a MAC address table capable of handling up to 2000 entries and offers a switching capacity of 10 Gbit/s. The device complies with several networking standards, including IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, and IEEE 802.3z. It operates on a DC input voltage ranging from 12 to 58 volts and can be conveniently mounted on a wall for ease of placement.

Management features

Switch type
Switch type
Unmanaged
show more


Switch layer
Switch layer
L2
show more


Traffic shaping
Yes
show more

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
Basic switching RJ-45 Ethernet ports quantity
5
show more


Basic switching RJ-45 Ethernet ports type
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
show more

Network

Networking standards
Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3z
show more


10G support
10G support
No
show more


Full duplex
Full duplex
Yes
show more


Auto-negotiation
Yes
show more


Auto MDI/MDI-X
Auto MDI/MDI-X
Yes
show more


Flow control support
Yes
show more


Broadcast storm control
Yes
show more

Data transmission

Switching capacity
Switching capacity
10 Gbit/s
show more


Forwarding rate
7.44 Mpps
show more


MAC address table
MAC address table
2000 entries
show more


Store-and-forward
Yes
show more


Jumbo frames support
Yes
show more


Jumbo frames
9000
show more

Multicast features

Multicast support
Yes
show more

Design

Rack mounting
Rack mounting
No
show more


Product colour
Product colour
Black
show more


LED indicators
LAN, Power
show more


Wall mountable
Wall mountable
Yes
show more


DIN rail mounting
Yes
show more


Electromagnetic compatibility
Electromagnetic compatibility
FCC 15, EN 61000-6-2, EN 61000-6-4, EN 61000-4-2, -3, -4, -5, -6 (3)
show more

Power

DC input voltage
12 – 58 V
show more


Power consumption (max)
Power consumption (max)
3.57 W
show more

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
-40 – 75 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 85 °C
show more


Operating relative humidity (H-H)
5 – 95%
show more


Storage relative humidity (H-H)
0 – 95%
show more


Heat dissipation
Heat dissipation
12.18 BTU/h
show more

Weight & dimensions

Width
Width
112.2 mm
show more


Depth
Depth
29.1 mm
show more


Height
Height
89.4 mm
show more


Weight
Weight
300 g
show more

Packaging data

Package width
Package width
140 mm
show more


Package depth
Package depth
178 mm
show more


Package height
Package height
83 mm
show more


Package weight
Package weight
500 g
show more

Technical details

Pallet gross weight (sea)
321.6 kg
show more


Pallet height (air)
136.5 cm
show more


Pallet gross width
110 cm
show more


Master (outer) cases per pallet (sea)
54 pc(s)
show more


Products per pallet (sea)
540 pc(s)
show more


Shipping (inner) case gross weight
5.64 kg
show more


Pallet height (sea)
198 cm
show more


Pallet gross length
120 cm
show more


Products per pallet (air)
360 pc(s)
show more


Shipping (inner) case length
44 cm
show more


Shipping (inner) case width
30.5 cm
show more


Shipping (inner) case net weight
5 kg
show more


Products per shipping (inner) case
10 pc(s)
show more


Master (outer) cases per pallet (air)
36 pc(s)
show more


Pallet gross weight (air)
220 kg
show more


Shipping (inner) case height
20.5 cm
show more

Certificates

Certification
IEC60068-2-6; IEC60068-2-27; IEC60068-2-32; UL 60950-1, CE, FCC, RoHS, WEEE
show more

Logistics data

Harmonized System (HS) code
85176990
