CAT 6A U-UTP Installation Cable, 500 MHz Dca (LSZH-1), AWG 23/1, 100 m Drum, SX, Blue

The DIGITUS DK-1614-A-VH-1 is a high-performance CAT 6A cable built for reliable data transmission across various applications. It consists of 8 insulated conductors twisted into 4 pairs, which ensures optimal signal integrity with an impedance of 100±5 Ohm at frequencies up to 600 MHz. Each conductor is made from bare annealed copper, and the insulation is crafted from high-density polyethylene (HD-PE) for excellent durability and performance. The cable's outer sheath is compliant with low smoke zero halogen (LSZH) standards, making it suitable for installations where fire safety is a priority.

The cable is designed to operate under a wide range of conditions, with an operating temperature range from -20 °C to +75 °C and a shipping and storage temperature range from -20 °C to +60 °C. Its robust construction can endure a maximum tensile load of 150N and a dynamic bending radius of at least 8 times the cable diameter. With a length of 100 meters and a light blue color (RAL 5012), the DIGITUS DK-1614-A-VH-1 cable is a top choice for high-speed networking applications, offering reliable performance and compliance with industry standards.
