Industrial Gigabit PoE+ Injector 802.3at with 60W Power Output and DIN Rail and Wall Mount Design

The Digitus Industrial Gigabit Ethernet PoE+ Injector is a device designed for providing power and data over a single Ethernet cable. It supports the 802.3 af/at standard and offers up to 60 watts of output power. The injector features a Gigabit Ethernet interface, supporting data rates of 10, 100, and 1000 Mbit/s, and adheres to the IEEE 802.3at networking standard. Its design is sleek and black, with LED indicators for PoE and power status. It includes power protection features such as over-voltage and short circuit protection. The Power over Ethernet (PoE) voltage supplied is 55 volts, with a maximum power consumption of 3 watts. The injector weighs 300 grams and its dimensions are 77 x 103 x 32 mm. It is sold individually, with one unit per package.

Network

Ethernet interface type
Gigabit Ethernet
show more


Ethernet LAN data rates
Ethernet LAN data rates
10,100,1000 Mbit/s
show more


Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
show more


Networking standards
Networking standards
IEEE 802.3at
show more

Features

Product colour
Product colour
Black
show more


Wall mountable
Wall mountable
Yes
show more


LED indicators
PoE, Power
show more


Power protection features
Power protection features
Over voltage, Short circuit
show more

Ports & interfaces

Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
2
show more


DC-in jack
DC-in jack
Yes
show more

Power

Power over Ethernet (PoE) voltage
Power over Ethernet (PoE) voltage
55 V
show more


Output power
Output power
60 W
show more


Power consumption (max)
Power consumption (max)
3 W
show more


Total Power over Ethernet (PoE) budget
60 W
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
-40 – 75 °C
show more

Weight & dimensions

Weight
Weight
300 g
show more


Dimensions (WxDxH)
Dimensions (WxDxH)
77 x 103 x 32 mm
show more

Packaging content

Number of products included
Number of products included
1 pc(s)
show more


Quick installation guide
Yes
show more

Packaging data

Package width
Package width
125 mm
show more


Package depth
Package depth
165 mm
show more


Package height
Package height
50 mm
show more


Package weight
Package weight
410 g
show more


Package volume
1031.25 cm³
show more

Logistics data

UK Trade Tariff code
85176200
show more


Harmonized System (HS) code
85044095
show more


Master (outer) case width
350 mm
show more


Master (outer) case height
330 mm
show more


Master (outer) case gross weight
390 g
show more


Master (outer) case volume
45045 cm³
show more


Products per master (outer) case
36 pc(s)
show more


Country of origin
Country of origin
China
show more
