Fast Ethernet Media Converter with Multimode ST Connector, 1310nm, Up to 2km

The Digitus Fast Ethernet Media Converter is designed to facilitate the conversion between 100Base-TX and 100Base-FX interfaces. It adheres to networking standards IEEE 802.3 and IEEE 802.3u. The device supports a maximum transfer distance of up to 2000 meters and operates at a wavelength of 1310 nm, utilizing a multi-mode fiber structure. The media converter comes equipped with LED indicators that display activity, link, and power status, ensuring easy monitoring. The product is finished in a sleek black color. It features an ST fiber optic connector and supports wired connectivity technology. The converter operates with an input voltage of 5 V and has a typical power consumption of 2.5 W.

Network

Converter input interface
Converter input interface
100Base-TX
show more


Converter output interface
100Base-FX
show more


Networking standards
Networking standards
IEEE 802.3, IEEE 802.3u
show more


Ethernet interface type
Fast Ethernet
show more


Ethernet LAN data rates
Ethernet LAN data rates
10,100 Mbit/s
show more


Auto MDI/MDI-X
Auto MDI/MDI-X
Yes
show more


Duplex system
Duplex system
Full, Half
show more

Performance

Maximum transfer distance
Maximum transfer distance
2000 m
show more


Wavelength
Wavelength
1310 nm
show more


Fiber mode structure
Multi-mode
show more


Fiber cable diameters supported (core/cladding)
50/125,62.5/125 µm
show more


Tx power (min)
-22 dBmW
show more


Tx power (max)
-12 dBmW
show more


Rx power (min)
-30 dBmW
show more


Buffer size
Buffer size
128 KB
show more

Features

Internal
Internal
Yes
show more


Product colour
Product colour
Black
show more


LED indicators
Activity, Link, Power
show more

Ports & interfaces

Connectivity technology
Connectivity technology
Wired
show more


Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
1
show more


Fiber ports quantity
Fiber ports quantity
1
show more


Fiber optic connector
Fiber optic connector
ST
show more


DC-in jack
DC-in jack
Yes
show more

Power

Input voltage
Input voltage
5 V
show more


Power consumption (typical)
Power consumption (typical)
2.5 W
show more


Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
show more


External power adapter
Yes
show more

Weight & dimensions

Weight
Weight
200 g
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
0 – 55 °C
show more

Packaging content

User guide
Yes
show more

Packaging data

Package width
Package width
216 mm
show more


Package depth
Package depth
60 mm
show more


Package volume
2086.56 cm³
show more


Package weight
Package weight
500 g
show more

Logistics data

Harmonized System (HS) code
85176990
show more


UK Trade Tariff code
85176200
show more


Country of origin
Country of origin
China
show more

Other features

Transmission distance (max)
2 km
show more


Dimensions (WxDxH)
Dimensions (WxDxH)
95 x 70 x 26 mm
show more
