8+2 Port GE PoE Switch with 8 Port PoE 802.3at, 10/100/1000 Mbps and 2 Port GE

The Digitus 8-Port Gigabit PoE Network Switch is designed for desktop use and is an unmanaged switch. It provides a power capacity of 60 watts and supports both af and at standards. The switch includes basic switching RJ-45 Ethernet ports, which have a Fast Ethernet capability of 10/100. There is a total of 10 Ethernet ports available. The switch supports full duplex communication and has a MAC address table capable of storing up to 2000 entries. It adheres to various networking standards, including IEEE 802.3, IEEE 802.3af, IEEE 802.3at, and IEEE 802.3x. The power connector type is an AC-in jack, and the switch supports Power over Ethernet (PoE).

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
Basic switching RJ-45 Ethernet ports quantity
10
show more


Basic switching RJ-45 Ethernet ports type
Basic switching RJ-45 Ethernet ports type
Fast Ethernet (10/100)
show more


Fast Ethernet (copper) ports quantity
10
show more


Power connector
AC-in jack
show more

Network

Networking standards
Networking standards
IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
show more


10G support
10G support
No
show more


Copper ethernet cabling technology
10BASE-TX, 1000BASE-T
show more


Cable types supported
Cat3, Cat4, Cat5, Cat5e
show more


Full duplex
Full duplex
Yes
show more


Half duplex
Yes
show more


Ethernet LAN data rates
Ethernet LAN data rates
10,100 Mbit/s
show more


Flow control support
Yes
show more

Data transmission

Forwarding rate
14.88 Mpps
show more


MAC address table
MAC address table
2000 entries
show more


Store-and-forward
Yes
show more


Jumbo frames support
Yes
show more


Jumbo frames
9216
show more


Packet buffer memory
2 MB
show more

Design

Rack mounting
Rack mounting
No
show more


Stackable
Stackable
No
show more


Product colour
Product colour
Black
show more


LED indicators
Activity, PoE, Link, Power
show more

Performance

Mean time between failures (MTBF)
Mean time between failures (MTBF)
50000 h
show more

Power

Power source
Power source
AC
show more


Power supply included
Power supply included
Yes
show more


AC input voltage
AC input voltage
100 – 240 V
show more


AC input frequency
50 – 60 Hz
show more


Power consumption (typical)
Power consumption (typical)
65 W
show more


Surge protection
Yes
show more


Surge protection voltage
2 kV
show more

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
show more


Power over Ethernet (PoE) ports quantity
8
show more


Power over Ethernet (PoE) power per port
30 W
show more


Total Power over Ethernet (PoE) budget
60 W
show more

Other features

Bandwidth
20 Gbit/s
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
0 – 40 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 70 °C
show more


Operating relative humidity (H-H)
10 – 90%
show more


Storage relative humidity (H-H)
5 – 90%
show more

Weight & dimensions

Width
Width
168 mm
show more


Depth
Depth
93 mm
show more


Height
Height
32 mm
show more

Packaging content

Cables included
AC
show more


Quick start guide
Quick start guide
Yes
show more

Packaging data

Package width
Package width
192 mm
show more


Package depth
Package depth
237 mm
show more


Package volume
3958.85 cm³
show more


Package height
Package height
87 mm
show more


Package weight
Package weight
1.03 kg
show more

Logistics data

UK Trade Tariff code
85176200
show more


Country of origin
Country of origin
China
show more
