IT BASIC PDU, Vertical, 16A, 24 x C13, 3 x C19 1-phase, 3m Cable, IEC309 16A Plug

The Digitus Basic IT PDU is a single-phase power distribution unit designed with a 16A capacity. It features a total of 27 AC outlets, including 24 C13 couplers and 3 C19 couplers. The PDU is equipped with a 3-meter supply cable and an IEC 60309 16A power plug. With a nominal input voltage of 250V and a maximum current of 16A, it operates within an AC input frequency range of 50 to 60 Hz. The unit is a basic type PDU, specifically designed for rack mounting with a capacity of 0U. Its dimensions are 45 mm in width, 1140.5 mm in depth, and 60 mm in height.

Design

PDU types
PDU types
Basic
show more


Type
Type
Single-phase
show more


Rack capacity
Rack capacity
0U
show more


Mounting
Mounting
Vertical
show more


Housing material
Housing material
ABS synthetics, Aluminium
show more


Product colour
Product colour
Black
show more

Ports & interfaces

AC outlets quantity
AC outlets quantity
27 AC outlet(s)
show more


Power plug
Power plug
IEC 60309
show more


AC outlet types
AC outlet types
C13 coupler, C19 coupler
show more


Master AC outlets quantity
24
show more


Slave AC outlets quantity
3
show more

Features

Cable length
Cable length
3 m
show more

Power

Nominal input voltage
Nominal input voltage
250 V
show more


AC input frequency
50 – 60 Hz
show more


Maximum current
Maximum current
16 A
show more


Block 1 output current
10 A
show more


Block 2 output current
16 A
show more


Nominal output voltage
Nominal output voltage
230 V
show more


Output voltage
230 V
show more


Load capacity
3600 VA
show more


Number of phases
1
show more


Maximum power
Maximum power
4000 W
show more

Weight & dimensions

Width
Width
45 mm
show more


Depth
Depth
1140.5 mm
show more


Height
Height
60 mm
show more

Packaging content

Manual
Yes
show more

Packaging data

Package weight
Package weight
3.35 kg
show more


Package width
Package width
145 mm
show more


Package depth
Package depth
1400 mm
show more


Package volume
14210 cm³
show more

Logistics data

Country of origin
Country of origin
China
show more


UK Trade Tariff code
85444290
show more
