4×4 HDMI Matrix Switch, 4K/60Hz 18 Gps, HDR, EDID, Downscaler, HDCP 2.2

Introducing the Digitus 4×4 HDMI Matrix Switch, designed to deliver superior video quality with support for 4K resolution at 60Hz. It accommodates a maximum resolution of 3840 x 2160 pixels, ensuring clear and detailed images, and boasts a bandwidth of 18 Gbit/s for smooth data transfer. The maximum resolution for HDMI connections is also 3840 x 2160 pixels, making it an ideal choice for high-definition displays.

The unit is housed in a durable metal enclosure, presented in a sleek black finish, providing both style and reliability. It features a Micro-USB connector type for seamless integration with other devices. The switch is efficient in its power usage, with a maximum consumption of 11.04 watts. It operates with an output current of 2500 mA and an output voltage of 12 volts, ensuring stable performance.

This product is manufactured in China and is designed to meet the needs of users who demand high-quality video output and robust connectivity options in their multimedia setups.

Features

Maximum resolution
Maximum resolution
3840 x 2160 pixels
show more


Bandwidth
18 Gbit/s
show more


Maximum resolution (HDMI)
3840 x 2160 pixels
show more


HDCP
HDCP
Yes
show more


HDCP version
1.4/2.2
show more


High Dynamic Range (HDR) supported
Yes
show more


Extended display identification data (EDID)
Yes
show more


EDID management
Yes
show more

Design

Housing colour
Housing colour
Black
show more


Housing material
Housing material
Metal
show more


LED indicators
Yes
show more

Display

Built-in display
Built-in display
No
show more

Ports & interfaces

HDMI input ports quantity
4
show more


HDMI output ports quantity
4
show more


HDMI version
2.0
show more


USB connector type
USB connector type
Micro-USB
show more


USB ports quantity
1
show more


DC-in jack
DC-in jack
Yes
show more

Power

Power consumption (max)
Power consumption (max)
11.04 W
show more


Output voltage
12 V
show more


Output current
2500 mA
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
0 – 40 °C
show more

Technical details

Package volume
3750.02 cm³
show more

Logistics data

Harmonized System (HS) code
85299097
show more


Country of origin
Country of origin
China
show more

Weight & dimensions

Width
Width
220 mm
show more


Depth
Depth
105 mm
show more


Height
Height
19 mm
show more


Weight
Weight
535 g
show more


Package type
Package type
Box
show more


Package width
Package width
309 mm
show more


Package depth
Package depth
164 mm
show more


Package height
Package height
61 mm
show more


Package weight
Package weight
1.09 kg
show more

Packaging content

Manual
Yes
show more


Mounting brackets included
Yes
show more


AC adapter included
Yes
show more
