Zebra DS8108-SR Handheld Bar Code Reader 1D/2D LED Black

The Zebra DS8108-SR is a handheld barcode reader featuring a scanner capable of reading both 1D and 2D barcodes. It utilizes an LED sensor for scanning. This device is designed for wired connectivity and can interface with systems using RS-232, USB, or a keyboard wedge. Connections to a PC can be made via RS-232 or USB ports. The product is black in color and has an International Protection (IP) code of IP42, indicating resistance to dust and moisture to a certain extent. It operates at an input voltage of 5 volts with a power consumption of 450 mA. The product is lightweight at 154 grams and measures 66 mm in width and 107 mm in depth.

Scanning

Type
Type
Handheld bar code reader
show more


Scanner type
Scanner type
1D/2D
show more


Linear (1D) barcodes supported
Linear (1D) barcodes supported
Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, Plessey, U.P.C.
show more


2D (matrix & stacked) barcodes supported
2D (matrix & stacked) barcodes supported
Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
show more


Sensor type
Sensor type
LED
show more


Wavelength
Wavelength
617 nm
show more


Tilt reading angle
0 – 360°
show more


Pitch reading angle
0 – 60°
show more


Yaw reading angle
0 – 60°
show more

Ports & interfaces

Connectivity technology
Connectivity technology
Wired
show more


Standard interfaces
Standard interfaces
RS-232, USB, Keyboard wedge
show more


PC connection
RS-232/USB
show more

Performance

International Protection (IP) code
International Protection (IP) code
IP42
show more


Product colour
Product colour
Black
show more

Power

Input voltage
Input voltage
5 V
show more


Power consumption
450 mA
show more

Weight & dimensions

Width
Width
66 mm
show more


Depth
Depth
107 mm
show more


Height
Height
168 mm
show more


Weight
Weight
154 g
show more

Packaging data

Cables included
USB
show more

Operational conditions

Operating relative humidity (H-H)
5 – 95%
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 70 °C
show more


Operating temperature (T-T)
Operating temperature (T-T)
0 – 50 °C
show more

Logistics data

Harmonized System (HS) code
84716070
