D-Link DXS-1210-12SC/E Network Switch Managed L2 10G Ethernet (100/1000/10000) 1U Black, Silver

The D-Link DXS-1210-12SC/E is a managed switch designed for Layer 2 operations. It features two RJ-45 Ethernet ports, supporting 10G Ethernet speeds of 100/1000/10000. The switch can manage up to 16,000 MAC address entries and offers a switching capacity of 240 Gbit/s. It complies with several networking standards, including IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, and IEEE 802.3z. This switch is suitable for rack mounting and has a 1U form factor.

Management features

Switch type
Switch type
Managed
show more


Switch layer
Switch layer
L2
show more


Quality of Service (QoS) support
Yes
show more


MIB support
Y
show more

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
Basic switching RJ-45 Ethernet ports quantity
2
show more


Basic switching RJ-45 Ethernet ports type
Basic switching RJ-45 Ethernet ports type
10G Ethernet (100/1000/10000)
show more


SFP+ module slots quantity
10
show more


Fiber optic connector
Fiber optic connector
SFP+
show more

Network

Networking standards
Networking standards
IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z
show more


10G support
10G support
Yes
show more


Cable types supported
Cat6, Cat6a, Cat7
show more


Auto MDI/MDI-X
Auto MDI/MDI-X
Yes
show more


Spanning tree protocol
Yes
show more


VLAN support
VLAN support
Yes
show more

Data transmission

Switching capacity
Switching capacity
240 Gbit/s
show more


Throughput
178.56 Mpps
show more


MAC address table
MAC address table
16000 entries
show more


Jumbo frames support
Yes
show more

Security

IGMP snooping
Yes
show more

Design

Rack mounting
Rack mounting
Yes
show more


Form factor
Form factor
1U
show more


Product colour
Product colour
Black, Silver
show more


LED indicators
Yes
show more


Safety
Safety
cUL, CB, CE, CCC, BSMI
show more

Power

AC input voltage
AC input voltage
100 – 240 V
show more


Power consumption (typical)
Power consumption (typical)
43.81 W
show more

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
-5 – 50 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 70 °C
show more


Operating relative humidity (H-H)
0 – 95%
show more

Weight & dimensions

Width
Width
210 mm
show more


Depth
Depth
440 mm
show more


Height
Height
44 mm
show more


Weight
Weight
2.73 kg
show more

Packaging data

Package width
Package width
349 mm
show more


Package depth
Package depth
546 mm
show more


Package height
Package height
96 mm
show more


Package weight
Package weight
3.91 kg
show more

Sustainability

Sustainability certificates
ENERGY STAR
show more

Technical details

Pallet gross weight (sea)
399.6 kg
show more


Pallet height (air)
128.4 cm
show more


Pallet gross width
120 cm
show more


Master (outer) cases per pallet (sea)
30 pc(s)
show more


Products per pallet (sea)
90 pc(s)
show more


Shipping (inner) case gross weight
12.7 kg
show more


Pallet height (sea)
2.05 m
show more


Pallet gross length
110 cm
show more


Products per pallet (air)
54 pc(s)
show more


Shipping (inner) case length
56.2 cm
show more


Shipping (inner) case width
31.4 cm
show more


Shipping (inner) case net weight
11.7 kg
show more


Products per shipping (inner) case
3 pc(s)
show more


Master (outer) cases per pallet (air)
18 pc(s)
show more


Pallet gross weight (air)
247.3 kg
show more


Shipping (inner) case height
38.3 cm
show more

Logistics data

Harmonized System (HS) code
85176990
