APC Easy UPS 3S Double-conversion Online 40 kVA 40000 W

The APC Easy UPS 3S is a double-conversion (online) uninterruptible power supply with an output power capacity of 40 kVA, delivering up to 40,000 watts of power. It features an RS-232 serial interface for connectivity. The UPS utilizes sealed lead acid (VRLA) battery technology with a voltage of 240 V and provides a typical backup time of 10 minutes at full load. Designed with a tower form factor, the product is available in white and comes equipped with an LCD display for monitoring. The UPS complies with several standards and certifications including RoHS, CE, EAC, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE, and REACH.

Features

UPS topology
UPS topology
Double-conversion (Online)
show more


Output power capacity
Output power capacity
40 kVA
show more


Output power
Output power
40000 W
show more


Waveform
Pure sine
show more


Input operation voltage (min)
Input operation voltage (min)
304 V
show more


Input operation voltage (max)
Input operation voltage (max)
477 V
show more


Input frequency
Input frequency
50/60 Hz
show more


Output operation voltage (min)
Output operation voltage (min)
380 V
show more


Output operation voltage (max)
Output operation voltage (max)
400 V
show more


Output frequency regulation
45 – 65 Hz
show more


Maximum current
Maximum current
73 A
show more


Number of input phases
3
show more


Number of output phases
3
show more


Efficiency
96%
show more


Emergency Power Off (EPO)
Yes
show more


Output voltage Total Harmonic Distortion (THD)
3%
show more


Noise level
Noise level
63 dB
show more

Ports & interfaces

USB port
USB port
Yes
show more


Serial interface
Yes
show more


Serial interface type
RS-232
show more

Battery

Battery technology
Battery technology
Sealed Lead Acid (VRLA)
show more


Battery voltage
Battery voltage
240 V
show more


Typical backup time at full load
Typical backup time at full load
10 min
show more

Design

Form factor
Form factor
Tower
show more


Product colour
Product colour
White
show more


Display type
Display type
LCD
show more


International Protection (IP) code
International Protection (IP) code
IP20
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
0 – 40 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-15 – 40 °C
show more


Operating relative humidity (H-H)
0 – 95%
show more


Storage relative humidity (H-H)
0 – 95%
show more


Operating altitude
0 – 9999 m
show more


Non-operating altitude
0 – 15000 m
show more

Safety regulation & standards

Safety
Safety
IEC 62040-1-1
show more

Certificates

Compliance certificates
RoHS
show more


Certification
CE, EAC, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE, REACH
show more

Weight & dimensions

Width
Width
500 mm
show more


Depth
Depth
969 mm
show more


Height
Height
1400 mm
show more


Weight
Weight
590 kg
show more

Packaging data

Package width
Package width
683 mm
show more


Package depth
Package depth
1114 mm
show more


Package height
Package height
1640 mm
show more


Package weight
Package weight
643 kg
show more

Logistics data

Harmonized System (HS) code
85078000
