The Ubiquiti EdgeRouter 10X is designed to meet advanced networking needs. It supports networking standards such as IEEE 802.1Q and IEEE 802.3ad. The router is equipped with various routing protocols including BGP, MPLS, OSPF, OSPFv3, RIP, RIPng, and VRRP, making it versatile for different routing applications. In terms of security, it utilizes SNMP algorithms and supports VPN connections, offering IPSec Site-to-Site and Remote Access and OpenVPN for both Site-to-Site and Remote Access, as well as PPTP Remote Access.
Powered by a processor with a frequency of 880 MHz, the device provides efficient performance, complemented by 512 MB of flash memory and 512 MB of internal memory. With its sleek black design, the router is housed in a durable metal casing. It features LED indicators that display activity, link, and Power over Ethernet (PoE) status, ensuring easy monitoring and management.
| Mechanical | |
|---|---|
| Dimensions | 268.1 x 136.5 x 31.1 mm (10.6 x 5.4 x 1.2") |
| Weight | 600 g (1.3 lb) |
| Hardware | |
| Processor | Dual-core 880 MHz, MIPS1004Kc |
| System memory | 512 MB DDR3 RAM |
| On-board flash storage | 512 MB NAND |
| Networking interface | (10) 10/100/1000 RJ45 ports |
| Management interface | (1) RJ45 serial port |
| PoE interface | PoE In: (1) 24V passive PoE port, 2-pair (4, 5+; 7, 😎 PoE Out: (1) 24V passive PoE port, 2-pair (4, 5+; 7, 😎 |
| Power method | AC/DC power adapter, 24W, 24V, 1A (Included) 24V passive PoE |
| Power supply | External AC/DC adapter |
| Supported voltage range | DC: 9-30V DC 24V passive PoE: 20-30V DC |
| Max. power consumption | 8W (Excludes PoE output) |
| Passive PoE Max. wattage per port | 15W (24V, 0.63A) |
| Passive PoE output | DC/PoE passthrough |
| Button | Factory reset |
| LEDs | Link/activity, PoE |
| Layer 3 forwarding performance | Packet size: 64 bytes – 260,000 pps Packet size: 1518 bytes or larger – 1 Gbps (Line rate) |
| Mounting | Wall, rack* With optional rack mount kit, model ER-RMKIT. |
| Ambient operating temperature | -10 to 45° C (14 to 113° F) |
| Ambient operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
