Set Hybrid 10kW + Inverter FoxESS H3-10.0-E + Energy Storage FoxESS CUBE H3-5.0-E + 18x Jinko Bifacial 575Wp

Hybrid Set 10 kWp with JASolar 575Wp Modules Black Frame is an advanced solar power system that combines efficient energy conversion and storage. It includes a Hybrid Inverter FoxESS H3-10.0-E and energy storage FoxESS CUBE ECS2900-H2 with a capacity of 5.76 kWh.

Inverter Specifications:
– The hybrid inverter model H3-10.0-E operates on three phases.
– It features a PV Point backup power function and 2 MPPT chains for optimized energy management.
– The inverter supports both Wi-Fi and Ethernet communication for seamless connectivity.
– Comes with a 5-year product warranty.

Photovoltaic Module Details:
– The set includes 18 high-quality JINKO JKM575N-72HL4-BDV modules.
– Jinko, a leading manufacturer of photovoltaic cells and modules, utilizes N-Type technology in these modules.
– The modules boast an impressive efficiency of 22.26% and provide higher output power.
– They have a sleek silver frame and incorporate SMBB technology.
– The dimensions of each module are 2278x1134x30mm.
– Each module comes with a 15-year product warranty and a 25-year performance warranty.

Energy Storage Features:
– The energy storage solution, ECS2900-H2, offers high voltage storage with a capacity of 5.76 kWh.
– This storage is scalable, allowing an increase in capacity up to 20.16 kWh.
– It supports a discharge capability of up to 90% and is easy to install.
– The energy management system can be conveniently controlled via an app.

Additional Components:
– The system includes an Energy Meter DTSU666, which is provided with the inverter for comprehensive energy monitoring and management.
