NETGEAR GC728XP-100EUS Insight 1G-28P-POE+SFP+ Cloud Switch

The NETGEAR GC728XP is a managed network switch that supports Layer 2, Layer 3, and Layer 4 networking functions. It features 24 Gigabit Ethernet (10/100/1000) RJ-45 ports for basic switching, along with one USB 2.0 port. The switch can accommodate up to 16,000 MAC addresses and has a switching capacity of 92 Gbit/s. It complies with various networking standards, including IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, and IEEE 802.1x. The device includes a DC-in jack for power connection and supports Power over Ethernet (PoE). It is designed for rack mounting and has a form factor of 1U.

Management features

Switch type
Switch type
Managed
show more


Switch layer
Switch layer
L2/L3/L4
show more


Quality of Service (QoS) support
Yes
show more


Web-based management
Web-based management
Yes
show more


ARP inspection
Yes
show more


System event log
Yes
show more

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
Basic switching RJ-45 Ethernet ports quantity
24
show more


Basic switching RJ-45 Ethernet ports type
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
show more


SFP module slots quantity
2
show more


SFP+ module slots quantity
2
show more


USB 2.0 ports quantity
USB 2.0 ports quantity
1
show more


Power connector
DC-in jack
show more

Network

Networking standards
Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
show more


10G support
10G support
No
show more


Number of VLANs
256
show more

Data transmission

Switching capacity
Switching capacity
92 Gbit/s
show more


MAC address table
MAC address table
16000 entries
show more


Jumbo frames support
Yes
show more


Jumbo frames
9000
show more

Security

DHCP features
DHCP client
show more


Access Control List (ACL)
Yes
show more


Access Control List (ACL) rules
100
show more

Multicast features

Multicast support
Yes
show more


Number of multicast groups filtered
512
show more

Design

Rack mounting
Rack mounting
Yes
show more


Form factor
Form factor
1U
show more


Product colour
Product colour
White
show more


LED indicators
Yes
show more


Number of fans
Number of fans
2 fan(s)
show more

Performance

Processor frequency
Processor frequency
400 MHz
show more


Internal memory
Internal memory
1.5 MB
show more


Noise level
Noise level
39 dB
show more


Mean time between failures (MTBF)
Mean time between failures (MTBF)
629962 h
show more

Power

AC input voltage
AC input voltage
100 – 240 V
show more


AC input frequency
50 – 60 Hz
show more


Input current
1 A
show more


Power consumption (typical)
Power consumption (typical)
25.5 W
show more


Power consumption (max)
Power consumption (max)
437.1 W
show more

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
show more


Power over Ethernet (PoE) ports quantity
24
show more


Total Power over Ethernet (PoE) budget
390 W
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
0 – 50 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-20 – 70 °C
show more


Operating relative humidity (H-H)
0 – 90%
show more


Storage relative humidity (H-H)
0 – 95%
show more


Operating altitude
0 – 3000 m
show more


Heat dissipation
Heat dissipation
1491.45 BTU/h
show more

Weight & dimensions

Width
Width
440 mm
show more


Depth
Depth
224 mm
show more


Height
Height
44 mm
show more


Weight
Weight
3.79 kg
show more

Packaging content

Cables included
AC
show more


Quick start guide
Quick start guide
Yes
show more


Rack mount kit
Yes
show more

Packaging data

Rubber feet
Yes
show more

Certificates

Certification
CE, EN55032:2012+AC:2013, EN55024:2010+A1:2015, EN61000-3-2:2014, EN61000-3-3:2013, VCCI-CISPR 32:2016, RCM, AS/NZS CISPR 32:2015, ICES-003:2016, BSMI CNS13438, EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, UL 60950-1, 2nd, 2014 and CAN/CSA C22.2 No. 60950-1-07, 2nd, 2014, IEC 60950-1:2005, Am 1:2009, Am 2:2013, BSMI CNS14336-1, RCM, AS/NZS 60950.1:2015, KCC K60950-1, CCC GB4943.1-2011
show more

Logistics data

Harmonized System (HS) code
85176990
show more
