Netgear GS108LP – Unmanaged – Gigabit Ethernet (10/100/1000) – Power over Ethernet (PoE) – Rack Mounting – 1U – Wall Mountable (GS108LP-100EUS)

The NETGEAR GS108LP is an unmanaged switch featuring Gigabit Ethernet RJ-45 ports, which support 10/100/1000 Mbps speeds. It has a MAC address table that can accommodate up to 4,000 entries and offers a switching capacity of 16 Gbit/s. This switch complies with various networking standards, including IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, and IEEE 802.3i. It requires a DC input voltage of 54 V and includes an AC-in jack power connector. The switch supports Power over Ethernet (PoE) and can be mounted on a wall or in a rack, with a form factor of 1U.

Management features

Switch type
Switch type
Unmanaged
show more


Quality of Service (QoS) support
Yes
show more

Ports & interfaces

Basic switching RJ-45 Ethernet ports type
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
show more


Gigabit Ethernet (copper) ports quantity
8
show more


Power connector
AC-in jack
show more

Network

Networking standards
Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
show more


10G support
10G support
No
show more


Ethernet LAN data rates
Ethernet LAN data rates
10,100,1000 Mbit/s
show more


Flow control support
Yes
show more

Data transmission

Switching capacity
Switching capacity
16 Gbit/s
show more


MAC address table
MAC address table
4000 entries
show more


Store-and-forward
Yes
show more


Jumbo frames support
Yes
show more

Design

Rack mounting
Rack mounting
Yes
show more


Form factor
Form factor
1U
show more


Product colour
Product colour
Black, Grey
show more


LED indicators
Yes
show more


Number of fans
Number of fans
0 fan(s)
show more


Wall mountable
Wall mountable
Yes
show more

Performance

Buffer size
Buffer size
192 KB
show more


Plug and Play
Plug and Play
Yes
show more


Mean time between failures (MTBF)
Mean time between failures (MTBF)
2752476 h
show more

Power

Power source
Power source
DC/PoE
show more


DC input voltage
54 V
show more


Input current
1.25 A
show more


Power consumption (typical)
Power consumption (typical)
67.5 W
show more


Power consumption (max)
Power consumption (max)
130 W
show more

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
show more


Power over Ethernet plus (PoE+) ports quantity
8
show more


Total Power over Ethernet (PoE) budget
60 W
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
0 – 40 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-20 – 70 °C
show more


Operating relative humidity (H-H)
0 – 90%
show more


Storage relative humidity (H-H)
0 – 95%
show more


Operating altitude
0 – 1000 m
show more


Heat dissipation
Heat dissipation
230.85 BTU/h
show more

Weight & dimensions

Width
Width
236 mm
show more


Depth
Depth
102 mm
show more


Height
Height
27 mm
show more


Weight
Weight
600 g
show more

Logistics data

Harmonized System (HS) code
85176990
