Zyxel GS1900-8HP 8-Port GbE L2 PoE Smart Switch, 802.3at, Desktop, Fanless, 70 Watt

The Zyxel GS1900-8HP v3 is a managed network switch that operates at Layer 2. It features eight RJ-45 Ethernet ports with Gigabit Ethernet capability, supporting speeds of 10/100/1000 Mbps. This switch provides full duplex communication and can handle up to 8,000 MAC address entries. It has a switching capacity of 16 Gbit/s, ensuring efficient data transfer across the network. The device adheres to various networking standards, including IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, and IEEE 802.3af. For power options, it includes a DC-in jack and is capable of Power over Ethernet (PoE), allowing it to power compatible devices through its Ethernet ports.

Management features

Switch type
Switch type
Managed
show more


Switch layer
Switch layer
L2
show more


Quality of Service (QoS) support
Yes
show more


Web-based management
Web-based management
Yes
show more

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
Basic switching RJ-45 Ethernet ports quantity
8
show more


Basic switching RJ-45 Ethernet ports type
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
show more


Power connector
DC-in jack
show more

Network

Networking standards
Networking standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
show more


Full duplex
Full duplex
Yes
show more


Rate limiting
Yes
show more


Auto MDI/MDI-X
Auto MDI/MDI-X
Yes
show more


Broadcast storm control
Yes
show more


Flow control support
Yes
show more


VLAN support
VLAN support
Yes
show more

Data transmission

Switching capacity
Switching capacity
16 Gbit/s
show more


MAC address table
MAC address table
8000 entries
show more


Number of queues
8
show more


Jumbo frames support
Yes
show more


Jumbo frames
9216
show more

Security

DHCP features
DHCP client
show more


IGMP snooping
Yes
show more


MAC address filtering
MAC address filtering
Yes
show more


Security algorithms
Security algorithms
802.1x RADIUS
show more

Multicast features

Multicast support
Yes
show more

Design

Product colour
Product colour
Black
show more


Reset button
Yes
show more

Performance

Mean time between failures (MTBF)
Mean time between failures (MTBF)
533086 h
show more

Power

Power source
Power source
AC/DC
show more


AC input voltage
AC input voltage
100 – 240 V
show more


AC input frequency
50 – 60 Hz
show more


Power consumption (typical)
Power consumption (typical)
90 W
show more

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
show more


Power over Ethernet (PoE) ports quantity
8
show more


Total Power over Ethernet (PoE) budget
70 W
show more

Operational conditions

Operating relative humidity (H-H)
10 – 90%
show more

Weight & dimensions

Width
Width
250 mm
show more


Depth
Depth
104 mm
show more


Height
Height
27 mm
show more


Weight
Weight
710 g
show more

Certificates

Certification
CE, FCC, C-Tick, RoHS
show more

Logistics data

Harmonized System (HS) code
85176990
show more
