Set Hybrid 5kW with Inverter GW5KN-ET PLUS and GoodWe LYNX HV 6.56kWh Energy Storage plus 9 Jinko Bifacial 575Wp Panels

Product Description:

The Hybrid Set is designed for efficient energy conversion and storage, featuring a 5 kWp system with JASolar 575Wp modules, a GoodWe GW5KN-ET PLUS Hybrid Inverter, and GoodWe LYNX HV F6.6-H PLUS energy storage.

Set Specifications:

1. **GoodWe GW5KN-ET PLUS Hybrid Inverter (3-Phase):**
– Offers a backup power function.
– Provides emergency power switch capabilities with UPS functionality below 10ms.
– Compatible with smart home integration.
– Features two MPPT strings for efficient energy conversion.
– Equipped with Wi-Fi communication for ease of monitoring.
– Comes with a 5-year product warranty for peace of mind.

2. **JINKO JKM575N-72HL4-BDV Photovoltaic Modules (9 Units):**
– Manufactured by a leading company in solar cells and modules.
– Utilizes advanced N-Type technology.
– Achieves a high module efficiency of 22.26%.
– Designed for higher output power.
– Features a durable silver frame.
– Incorporates SMBB technology.
– Each module measures 2278x1134x30mm.
– Comes with a 15-year product warranty and a 25-year performance guarantee.

3. **GoodWe Lynx Home F PLUS+ 6.56 kWh Energy Storage:**
– Delivers maximum backup power capability.
– Built to the highest safety standards.
– Ensures smart and efficient operational performance.
– Offers a long battery cycle lifespan.
– Allows connectivity of up to 8 towers in parallel (up to 131kWh).
– Utilizes reliable LFP cells for enhanced safety and efficiency.
– Supports remote diagnosis and updates through the inverter.

Additionally, the GM3000 energy meter is included with the inverter for comprehensive energy management.
