Cudy 5-Port Gigabit Industrial Switch Unmanaged

The Cudy IG1005 is an unmanaged switch featuring four Gigabit Ethernet (10/100/1000) RJ-45 ports and one installed SFP module. It supports full duplex operation and has a MAC address table capacity of 2000 entries. The device offers a switching capacity of 14 Gbit/s and is compatible with networking standards IEEE 802.3, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, and IEEE 802.3z. The switch operates with a DC input voltage ranging from 12 to 52 volts and is equipped with a DC-in jack power connector.

Management features

Switch type
Switch type
Unmanaged
show more

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
Basic switching RJ-45 Ethernet ports quantity
4
show more


Basic switching RJ-45 Ethernet ports type
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
show more


Gigabit Ethernet (copper) ports quantity
4
show more


Installed SFP modules quantity
Installed SFP modules quantity
1
show more


SFP module slots quantity
1
show more


Power connector
DC-in jack
show more

Network

Networking standards
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
show more


10G support
10G support
No
show more


Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-TX
show more


Cable types supported
Cat3, Cat4, Cat5, Cat6
show more


Full duplex
Full duplex
Yes
show more


Half duplex
Yes
show more


Ethernet LAN data rates
Ethernet LAN data rates
10,100,1000 Mbit/s
show more


Auto MDI/MDI-X
Auto MDI/MDI-X
Yes
show more

Optical fiber

Transmission distance (max)
10 km
show more


Maximum transfer distance (Single-mode)
100 m
show more

Data transmission

Switching capacity
Switching capacity
14 Gbit/s
show more


Forwarding rate
10.5 Mpps
show more


MAC address table
MAC address table
2000 entries
show more


Jumbo frames support
Yes
show more


Jumbo frames
9000
show more


Packet buffer memory
1.2 MB
show more

Protocols

Supported network protocols
Supported network protocols
IEEE802.3 10BASE-T; IEEE802.3i 10Base-T; IEEE802.3u 100Base-TX; IEEE802.3ab 1000Base-T; IEEE802.3z 1000Base-X; IEEE802.3x
show more

Design

Product colour
Product colour
Black
show more


Housing material
Housing material
Aluminium
show more


Reset button
Yes
show more


LED indicators
Yes
show more


DIN rail mounting
Yes
show more


International Protection (IP) code
International Protection (IP) code
IP40
show more

Performance

Mean time between failures (MTBF)
Mean time between failures (MTBF)
300000 h
show more

Power

Power source
Power source
DC
show more


Power supply included
Power supply included
No
show more


Redundant power supply (RPS) support
Redundant power supply (RPS) support
Yes
show more


DC input voltage
12 – 52 V
show more


Power consumption (max)
Power consumption (max)
3 W
show more


Surge protection
Yes
show more


Surge protection voltage
4 kV
show more

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
-40 – 85 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 85 °C
show more


Operating relative humidity (H-H)
5 – 95%
show more

Weight & dimensions

Width
Width
118 mm
show more


Depth
Depth
86 mm
show more


Height
Height
33.5 mm
show more


Weight
Weight
360 g
show more

Packaging data

Package weight
Package weight
460 g
show more

Sustainability

Sustainability compliance
Yes
show more

Certificates

Compliance certificates
CE
show more
