TP-Link LS1005G LiteWave 5-Port Gigabit Desktop Switch

The TP-Link LS1005G LiteWave 5-Port Gigabit Desktop Switch is designed to enhance your networking experience by offering high-speed connections for multiple devices. This unmanaged switch has five RJ-45 Ethernet ports that support Gigabit Ethernet (10/100/1000), ensuring efficient management of network traffic and robust data transfer rates. It features a MAC address table that can accommodate 2000 entries and a switching capacity of 10 Gbit/s, guaranteeing smooth data transmission with minimal congestion, making it ideal for both home and small office environments.

The LS1005G complies with various networking standards, such as IEEE 802.3i, IEEE 802.3u, and IEEE 802.3x, enhancing throughput and reducing network errors. This compliance not only boosts performance but also ensures compatibility with a wide range of devices. The switch operates on a DC input voltage of 5V, providing reliable power for continuous use.

A standout feature of the TP-Link LS1005G is its wall-mountable design, which offers flexibility in installation and placement, optimizing space and improving cable management. Its compact design, paired with its robust functionality, makes it an excellent choice for expanding network capacity without sacrificing performance. Trust in TP-Link's reputation for quality and innovation to meet your networking needs with this reliable and efficient solution.

Management features

Switch type
Switch type
Unmanaged
show more

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
Basic switching RJ-45 Ethernet ports quantity
5
show more


Basic switching RJ-45 Ethernet ports type
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
show more

Network

Networking standards
Networking standards
IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
show more


10G support
10G support
No
show more


Auto-negotiation
Yes
show more


Flow control support
Yes
show more


Auto MDI/MDI-X
Auto MDI/MDI-X
Yes
show more

Data transmission

Switching capacity
Switching capacity
10 Gbit/s
show more


Forwarding rate
7.4 Mpps
show more


MAC address table
MAC address table
2000 entries
show more


Store-and-forward
Yes
show more


Jumbo frames support
Yes
show more


Jumbo frames
16000
show more


Packet buffer memory
1.5 MB
show more

Design

Rack mounting
Rack mounting
No
show more


Product colour
Product colour
Black
show more


Housing material
Housing material
Plastic
show more


LED indicators
Yes
show more


Wall mountable
Wall mountable
Yes
show more


International Protection (IP) code
International Protection (IP) code
IP20, IP40
show more

Power

Power supply included
Power supply included
Yes
show more


DC input voltage
5 V
show more


Input current
0.6 A
show more


Power consumption (max)
Power consumption (max)
3.7 W
show more

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
0 – 40 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 70 °C
show more


Operating relative humidity (H-H)
10 – 90%
show more


Storage relative humidity (H-H)
5 – 90%
show more


Heat dissipation
Heat dissipation
12.617 BTU/h
show more

Weight & dimensions

Width
Width
90 mm
show more


Depth
Depth
72 mm
show more


Height
Height
23 mm
show more

Packaging content

Quick start guide
Quick start guide
Yes
show more

Packaging data

Package type
Package type
Box
show more

Certificates

Certification
CE, FCC, RoHS
show more

Logistics data

Harmonized System (HS) code
85176990
show more
