Supermicro A1SRM-2558F BGA 1283 micro ATX

The Supermicro A1SRM-2558F features an Intel processor with a BGA 1283 socket and a maximum processor thermal power of 15 watts. It supports DDR3-SDRAM memory types and offers a maximum internal memory capacity of 64 GB, with memory voltages of 1.35 V and 1.5 V. The storage drive interfaces supported are SATA II and SATA III. For network connectivity, it includes a Gigabit Ethernet interface. This component is designed for servers and is built in a micro ATX motherboard form factor.

Processor

Processor manufacturer
Processor manufacturer
Intel
show more


Processor socket
Processor socket
BGA 1283
show more


Processor number of cores supported
Processor number of cores supported
4
show more


Processor thermal power (max)
15 W
show more

Memory

Supported memory types
Supported memory types
DDR3-SDRAM
show more


Memory voltage
Memory voltage
1.35,1.5 V
show more


ECC сompatibility
ECC & Non-ECC
show more


Supported memory clock speeds
Supported memory clock speeds
1333,1600 MHz
show more


Maximum internal memory
Maximum internal memory
64 GB
show more

Storage controllers

Supported storage drive interfaces
SATA II, SATA III
show more

Internal I/O

USB 2.0 connectors
USB 2.0 connectors
3
show more


Number of SATA III connectors
Number of SATA III connectors
2
show more


Number of SATA II connectors
Number of SATA II connectors
4
show more


Chassis intrusion connector
Yes
show more


Serial port headers
1
show more


TPM connector
Yes
show more

Rear panel I/O ports

USB 2.0 ports quantity
USB 2.0 ports quantity
4
show more


Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
5
show more


VGA (D-Sub) ports quantity
VGA (D-Sub) ports quantity
1
show more


Serial ports quantity
Serial ports quantity
1
show more

Network

Ethernet LAN
Ethernet LAN
Yes
show more


Ethernet interface type
Gigabit Ethernet
show more


Wi-Fi
Wi-Fi
No
show more

Features

Component for
Component for
Server
show more


Motherboard form factor
Motherboard form factor
micro ATX
show more

Expansion slots

PCI Express x4 (Gen 2.x) slots
1
show more


PCI Express x8 (Gen 2.x) slots
PCI Express x8 (Gen 2.x) slots
1
show more

BIOS

BIOS type
BIOS type
UEFI AMI
show more


BIOS memory size
128 Mbit
show more


ACPI version
5.0
show more

Processor special features

Trusted Platform Module (TPM) version
1.2
show more


Trusted Platform Module (TPM)
Yes
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
0 – 60 °C
show more

Weight & dimensions

Width
Width
244 mm
show more


Depth
Depth
190.5 mm
show more

Packaging content

Bundled software
Bundled software
SuperDoctor 5, Watch Dog, NMI
show more

Other features

Supported DIMM module capacities
16GB, 2GB, 4GB, 8GB
show more


Number of processors supported
Number of processors supported
1
show more


Number of DIMM slots
Number of DIMM slots
4
show more
