Supermicro X10DAi Intel C612 LGA 2011 (Socket R) Extended ATX

The Supermicro X10DAi is a high-performance server motherboard designed for use with Intel processors. It features a processor socket of LGA 2011 (Socket R) and is compatible with the Intel Xeon E5-2600 series processors. The motherboard supports DDR4-SDRAM memory with a voltage of 1.2 V and is equipped with ECC compatibility to ensure data integrity. For storage, it offers SATA III interfaces and supports RAID configurations 0, 1, 5, and 10. Networking capabilities include a Gigabit Ethernet interface driven by an Intel I210 LAN controller. This motherboard is specifically designed for server applications and has an Extended ATX form factor, utilizing the Intel C612 chipset for optimal performance and reliability.

Processor

Processor manufacturer
Processor manufacturer
Intel
show more


Processor socket
Processor socket
LGA 2011 (Socket R)
show more


Intel Xeon series
E5-2600
show more


Processor number of cores supported
Processor number of cores supported
18
show more


Supported QPI
9.6 GT/s
show more


Processor thermal power (max)
145 W
show more

Memory

Supported memory types
Supported memory types
DDR4-SDRAM
show more


Memory voltage
Memory voltage
1.2 V
show more


ECC сompatibility
ECC
show more


Supported memory clock speeds
Supported memory clock speeds
1600,1866,2133 MHz
show more


Maximum RDIMM memory
512 GB
show more

Storage controllers

Supported storage drive interfaces
SATA III
show more


RAID levels
RAID levels
0, 1, 5, 10
show more

Internal I/O

Number of SATA III connectors
Number of SATA III connectors
10
show more

Rear panel I/O ports

USB 2.0 ports quantity
USB 2.0 ports quantity
5
show more


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
6
show more


Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
2
show more

Network

Ethernet LAN
Ethernet LAN
Yes
show more


Ethernet interface type
Gigabit Ethernet
show more


LAN controller
Intel I210
show more


Wake-on-LAN ready
Yes
show more


Wi-Fi
Wi-Fi
No
show more

Features

Motherboard chipset
Motherboard chipset
Intel® C612
show more


Audio output channels
Audio output channels
7.1 channels
show more


Component for
Component for
Server
show more


Motherboard form factor
Motherboard form factor
Extended ATX
show more

Expansion slots

PCI Express x4 (Gen 2.x) slots
1
show more


PCI Express x8 (Gen 3.x) slots
PCI Express x8 (Gen 3.x) slots
3
show more


PCI Express x16 (Gen 3.x) slots
PCI Express x16 (Gen 3.x) slots
3
show more

BIOS

BIOS type
BIOS type
AMI
show more


BIOS memory size
128 Mbit
show more


ACPI version
4.0
show more

Operational conditions

Storage temperature (T-T)
Storage temperature (T-T)
-40 – 70 °C
show more


Operating temperature (T-T)
Operating temperature (T-T)
10 – 35 °C
show more


Storage relative humidity (H-H)
5 – 95%
show more


Operating relative humidity (H-H)
8 – 90%
show more

Logistics data

Harmonized System (HS) code
84733020
show more

Weight & dimensions

Width
Width
305 mm
show more


Depth
Depth
330 mm
show more

Other features

Supported LRDIMM module capacity
64GB, 32GB
show more


Maximum LRDIMM memory
1 TB
show more


Supported RDIMM module capacity
16GB, 32GB, 4GB, 8GB
show more


Number of processors supported
Number of processors supported
2
show more


Number of DIMM slots
Number of DIMM slots
16
show more
