Supermicro MBD-X12SCA-5F-O X12SAE-5, ATX, LGA1200, Intel W580 Chipset, 4x DIMM/ECC

The Supermicro MBD-X12SCA-5F is a motherboard designed for high performance and reliability. It is compatible with Intel processors and features an LGA 1200 (Socket H5). The motherboard supports DDR4-SDRAM memory types and can accommodate up to 128 GB of internal memory. It comes with DIMM slots for easy installation of memory modules. For storage, it supports SATA III drive interfaces and offers RAID levels 0, 1, 5, and 10 for enhanced data protection and performance. The graphics capabilities are powered by the ASPEED graphics card family, featuring an AST2500 graphics card. Additionally, it provides HDMI version 2.0b and DisplayPort version 1.4a for high-quality video output.

Processor

Processor manufacturer
Processor manufacturer
Intel
show more


Processor socket
Processor socket
LGA 1200 (Socket H5)
show more


Maximum number of SMP processors
1
show more

Memory

Supported memory types
Supported memory types
DDR4-SDRAM
show more


Number of memory slots
4
show more


Memory slots type
Memory slots type
DIMM
show more


Memory voltage
Memory voltage
1.2 V
show more


ECC сompatibility
ECC & Non-ECC
show more


Supported memory clock speeds
Supported memory clock speeds
3200 MHz
show more


Maximum internal memory
Maximum internal memory
128 GB
show more

Storage controllers

Supported storage drive interfaces
SATA III
show more


RAID support
RAID support
Yes
show more


RAID levels
RAID levels
0, 1, 5, 10
show more

Graphics

Graphics card family
ASPEED
show more


Graphics card
AST2500
show more

Internal I/O

Number of SATA III connectors
Number of SATA III connectors
6
show more


TPM connector
Yes
show more


Number of COM connectors
1
show more

Rear panel I/O ports

USB 2.0 ports quantity
USB 2.0 ports quantity
2
show more


USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
4
show more


USB 3.2 Gen 2×2 Type-C ports quantity
1
show more


Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
2
show more


IPMI LAN (RJ-45) port
Yes
show more


VGA (D-Sub) ports quantity
VGA (D-Sub) ports quantity
1
show more


HDMI ports quantity
HDMI ports quantity
1
show more


HDMI version
2.0b
show more


DisplayPorts quantity
DisplayPorts quantity
1
show more


DisplayPort version
1.4a
show more


COM ports quantity
1
show more

Network

Ethernet LAN
Ethernet LAN
Yes
show more


Ethernet interface type
2.5 Gigabit Ethernet, Gigabit Ethernet
show more


LAN controller
Intel® I219-LM, Intel I225-LM
show more


Wi-Fi
Wi-Fi
No
show more

Features

Motherboard chipset
Motherboard chipset
Intel W580
show more


Audio chip
RealTek ALC888S
show more


PC health monitoring
CPU, Fan, LED, Voltage
show more


Component for
Component for
Server
show more


Motherboard form factor
Motherboard form factor
ATX
show more


Motherboard chipset family
Motherboard chipset family
Intel
show more

Expansion slots

PCI Express x1 (Gen 3.x) slots
2
show more


PCI Express x16 (Gen 4.x) slots
2
show more

BIOS

BIOS type
BIOS type
AMI
show more


BIOS memory size
256 Mbit
show more


ACPI version
6.0
show more


System Management BIOS (SMBIOS) version
3.0
show more

Operational conditions

Storage temperature (T-T)
Storage temperature (T-T)
-20 – 60 °C
show more


Operating temperature (T-T)
Operating temperature (T-T)
0 – 50 °C
show more

Logistics data

Harmonized System (HS) code
84733020
show more

Weight & dimensions

Width
Width
304.8 mm
show more


Depth
Depth
243.8 mm
show more
