PLANET L3 2-Port 100/1000T + 2-Port

The PLANET L3 Switch features 2-Port 100/1000T and 2-Port connectivity. It is a Managed type switch with Layer 3 functionality. It includes 2 basic switching RJ-45 Ethernet ports, along with 6 installed SFP modules and 2 installed SFP+ modules, supporting full duplex communication. The switch has a MAC address table capable of handling 8000 entries and offers a switching capacity of 68 Gbit/s. It adheres to multiple networking standards, including IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, and IEEE 802.1x. The device requires a DC input voltage of 24 V and is designed for rack mounting with a form factor of 1U.

Management features

Switch type
Switch type
Managed
show more


Switch layer
Switch layer
L3
show more


Quality of Service (QoS) support
Yes
show more


Cloud-managed
Yes
show more


Web-based management
Web-based management
Yes
show more


ARP inspection
Yes
show more


Traffic shaping
Yes
show more


Traffic classification
Yes
show more


System event log
Yes
show more

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
Basic switching RJ-45 Ethernet ports quantity
2
show more


Installed SFP modules quantity
Installed SFP modules quantity
6
show more


Installed SFP+ modules quantity
Installed SFP+ modules quantity
2
show more

Network

Networking standards
Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
show more


Full duplex
Full duplex
Yes
show more


MAC address auto-learning supported
Yes
show more


MAC address auto-aging supported
Yes
show more


Auto-negotiation
Yes
show more


Auto MDI/MDI-X
Auto MDI/MDI-X
Yes
show more


Link aggregation
Yes
show more


Rate limiting
Yes
show more


Spanning tree protocol
Yes
show more


VLAN support
VLAN support
Yes
show more

Data transmission

Switching capacity
Switching capacity
68 Gbit/s
show more


Throughput
50.59 Mpps
show more


MAC address table
MAC address table
8000 entries
show more


Store-and-forward
Yes
show more


Jumbo frames support
Yes
show more


Jumbo frames
10000
show more

Multicast features

Multicast support
Yes
show more

Design

Rack mounting
Rack mounting
Yes
show more


Form factor
Form factor
1U
show more


Product colour
Product colour
Blue
show more


LED indicators
Yes
show more

Power

Power source
Power source
AC/DC
show more


Redundant power supply (RPS) support
Redundant power supply (RPS) support
Yes
show more


AC input voltage
AC input voltage
100 – 240 V
show more


AC input frequency
50 – 60 Hz
show more


DC input voltage
24 V
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
-10 – 60 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-10 – 70 °C
show more


Operating relative humidity (H-H)
5 – 95%
show more


Storage relative humidity (H-H)
5 – 95%
show more

Weight & dimensions

Width
Width
330 mm
show more


Depth
Depth
153 mm
show more


Height
Height
44 mm
show more


Weight
Weight
1.49 kg
show more

Certificates

Certification
FCC Part 15 Class A, CE
