Zyxel NWA1123-AC Pro SU-MIMO 3×3 Standalone / NebulaFlex Access Wireless Point (includes passive PoE injector)

Comfortable network management is at the forefront with the Zyxel NWA1123-AC PRO access point, offering a total data transfer rate of up to 1.75 GB/s. The Zyxel NWA1123-AC PRO 802.11ac Hybrid Access Point boosts your experience with a combined data rate capability of up to 1.75 Gb/s. Thanks to its innovative dual-optimized design and the "RF First" commitment, this device ensures high performance and reliable connections, enhancing coverage and improving connection speeds for each client.

Functionality is matched with a modern design, eliminating the need to choose between performance and consistency in your network environment when deploying business access points. The stylish, contemporary casing of the NWA1123-AC PRO offers not only superior performance but also harmonizes perfectly with any interior setting.

Tailored specifically to meet your needs, this access point incorporates innovative software and meticulously developed hardware solutions to simplify optimization. With features such as DCS and a load balancing mechanism, the NWA1123-AC PRO allows you the freedom to enjoy high-quality Wi-Fi networks both in the workplace and at home.

For more detailed information, please refer to the manufacturer's documentation.

Features

2.4 GHz
Yes
show more


5 GHz
Yes
show more


Maximum data transfer rate
Maximum data transfer rate
1300 Mbit/s
show more


Ethernet LAN data rates
Ethernet LAN data rates
10,100,1000 Mbit/s
show more


Networking standards
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3au, IEEE 802.3az, IEEE 802.3u
show more


Channel bandwidth
80 MHz
show more


Modulation
Modulation
16-QAM, 64-QAM, 256-QAM, BPSK, QPSK
show more


Wi-Fi Multimedia (WMM)/(WME)
Yes
show more


VLAN support
VLAN support
Yes
show more


Wireless isolation
Yes
show more


Receiver sensitivity
-102 dBm
show more

Security

Security algorithms
Security algorithms
802.1x RADIUS, EAP-AKA, EAP-FAST, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, SNMP, SSH, WEP, WPA, WPA2-Enterprise, WPA2-PSK
show more


MAC address filtering
MAC address filtering
Yes
show more


Service Set Identifier (SSID) features
SSID broadcast on/off
show more


Number of SSID supported
16
show more

Protocols

DHCP client
DHCP client
Yes
show more

Ports & interfaces

Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
2
show more

Power

Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
show more

Design

Placement
Placement
Ceiling, Wall
show more


Product colour
Product colour
White
show more


Internal
Internal
No
show more

Antenna

Antenna gain level (max)
Antenna gain level (max)
5 dBi
show more

Certificates

Certification
FCC part 15C,
FCC part 15E,
ETSI EN 300 328,
EN 301 893,
LP0002
FCC part 15B,
EN 301 489-1,
EN 301 489-17,
EN55022,
EN55024,
EN61000-3-2/-3,
BSMI CNS13438
EN 60950-1,
IEC 60950-1,
BSMI CNS14336-1
show more

Weight & dimensions

Width
Width
203.9 mm
show more


Depth
Depth
191.7 mm
show more


Height
Height
34.7 mm
show more


Weight
Weight
445 g
show more

Packaging data

Package width
Package width
240 mm
show more


Package depth
Package depth
235 mm
show more


Package height
Package height
100 mm
show more


Package weight
Package weight
1.21 kg
show more

Packaging content

Quantity per pack
1 pc(s)
show more

Operational conditions

Operating relative humidity (H-H)
10 – 90%
show more


Operating temperature (T-T)
Operating temperature (T-T)
0 – 50 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 70 °C
show more


Storage relative humidity (H-H)
10 – 90%
show more

Logistics data

Harmonized System (HS) code
85176990
