QuOmni Wi-Fi 6E, Dual Band Concurrent Antenna for Wi-Fi 6E with 1Nm Connector

The QuWireless QuOmni Wi-Fi 6E features an omni-directional antenna with a maximum gain level of 7.5 dBi. It operates within the frequency bands of 2.4 – 2.5 GHz and 5 – 7.2 GHz, with a specific antenna gain of 6 dBi for the 2.4 GHz band. The antenna is equipped with an Nm connector type and supports vertical polarization. The device has a maximum power consumption of 50 watts. It measures 220 millimeters in height and 3 centimeters in diameter, with a weight of 200 grams. The product is sold in a package containing one piece.

Performance

Frequency band
Frequency band
2.4 – 2.5, 5 – 7.2 GHz
show more


Antenna gain (5 GHz)
7.5 dBi
show more


Antenna gain (2.4 GHz)
6 dBi
show more


Impedance
Impedance
50 Ω
show more


Antenna gain level (max)
Antenna gain level (max)
7.5 dBi
show more

Features

Antenna type
Antenna type
Omni-directional antenna
show more


Antenna connector type
Antenna connector type
Nm
show more


Polarization
Vertical polarization
show more


Voltage Standing Wave Ratio (VSWR)
2
show more


Product colour
Product colour
White
show more


Housing material
Housing material
Acrylonitrile butadiene styrene (ABS)
show more


International Protection (IP) code
International Protection (IP) code
IP67
show more


Purpose
Purpose
Indoor & outdoor
show more

Power

Power consumption (max)
Power consumption (max)
50 W
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
-40 – 80 °C
show more

Weight & dimensions

Height
Height
220 mm
show more


Diameter
Diameter
3 cm
show more


Weight
Weight
200 g
show more

Packaging content

Quantity per pack
1 pc(s)
show more
