Ubiquiti Networks PBE-5AC-500 Network Antenna Directional Antenna 27 dBi

The Ubiquiti PBE-5AC-500 is part of the AirMax PowerBeam AC series, known for its reliable performance. Operating in the 5 GHz band, this device achieves bandwidth levels of up to 450 Mbps. It is an ideal choice for situations demanding maximum bandwidth efficiency, capable of transmitting data at speeds up to 1000 Mbit/s. The PBE-5AC-500 includes one Ethernet LAN (RJ-45) port.

Functionality:
This Ubiquiti device functions as an AP/Bridge/CPE, adhering to 802.11ac standards and supporting the AirMax protocol. It features 136 MB of internal memory.

Construction:
Constructed from durable components, the device promises high quality and performance. It operates in temperatures from -40 to 70 degrees Celsius and in humidity levels from 5% to 95%.

Antenna:
The antenna boasts a maximum gain of 27 dBi, and InnerFeed technology integrally combines the antenna emitter with the radio module.

AirMax:
The PowerBeam AC series leverages AirMax technology to enhance bandwidth capabilities.

Key Features:
– Operates in the 5 GHz band
– Over 450 Mbps bandwidth
– More than 25 km range
– 27 dBi antenna gain

Application:
The PBE-5AC-500 is suitable for creating Point-to-Point links, making it ideal when maximum efficiency is crucial.

Power:
It consumes 8.5 W of power, and its design ensures a more concentrated beam, reducing network congestion. The device supports PoE and holds FCC, IC, and CE certifications.

Comparison of Models:
– All models operate in the 5 GHz frequency with throughput exceeding 450 Mbps.
– Range varies from 20+ km to 30+ km across models.
– Antenna gain ranges from 22 dBi to 29 dBi.
– Dish reflector sizes range from 300 mm to 620 mm.
– Networking interface consists of one 10/100/1000 Ethernet Port.

For more details, refer to the manufacturer's documentation and manual.
