Ubiquiti Networks PBE-5AC-620 Bridge/Repeater 1000 Mbit/s

Product Name: PBE-5AC-620 – Ubiquiti Complete Radio System

The Ubiquiti PBE-5AC-620 radio system is part of the AirMax NanoBeam M series, capable of operating in either Router or Bridge mode. It is known for its 450 Mbps bandwidth and offers protection from interference, allowing it to function effectively in locations with multiple networks. The device operates in the 5 GHz frequency band.

Performance:
This product is powered by a 720 MHz Atheros MIPS 74KC processor and includes 128 MB of internal memory alongside a 16 MB flash drive. It supports a maximum data transfer speed of 1000 Mbit/s and complies with the 802.11ac standard.

Capabilities:
Equipped with one Ethernet LAN port (RJ-45), the device features a maximum antenna gain of 29 dBi. It supports Power over Ethernet (PoE) technology, which enables power transfer via Ethernet cables. The PBE-5AC-620 is FCC, IC, and CE certified.

Usage:
Ideal for creating stable Point-to-Point links, the PBE-5AC-620 is efficient and user-friendly, with a straightforward installation process that does not require specialized tools.

AirMax Technology:
The PowerBeam AC series incorporates AirMax technology, enhancing bandwidth, interference resistance, and latency performance.

Key Features:
– Operates in the 5 GHz band
– Delivers 450+ Mbps bandwidth
– Offers a range of 30+ km
– Antenna gain of 29 dBi
– Durable construction
– AirMax and InnerFeed technologies
– Supports Router or Bridge mode

Construction:
The device features a durable build with cutting-edge solutions, making it reliable and robust. It is designed to operate effectively in temperatures ranging from -40 to 70 degrees Celsius.

Comparison:
– **PBE-5AC-300**
– Frequency: 5 GHz
– Throughput: 450+ Mbps
– Range: 20+ km
– Gain: 22 dBi
– Dish Reflector: 300 mm

– **PBE-5AC-400**
– Frequency: 5 GHz
– Throughput: 450+ Mbps
– Range: 25+ km
– Gain: 25 dBi
– Dish Reflector: 400 mm

– **PBE-5AC-500**
– Frequency: 5 GHz
– Throughput: 450+ Mbps
– Range: 25+ km
– Gain: 27 dBi
– Dish Reflector: 500 mm

– **PBE-5AC-620**
– Frequency: 5 GHz
– Throughput: 450+ Mbps
– Range: 30+ km
– Gain: 29 dBi
– Dish Reflector: 620 mm

Networking Interface:
Each model features a 10/100/1000 Ethernet port.

For further details, refer to the manufacturer's documentation and manual.
