The Ubiquiti NanoBeam PBE-M5-300 radio system operates in the 5 GHz band and adheres to the 802.11n MIMO 2×2 standard. It features a 560 MHz Atheros MIPS 74KC processor and possesses 64 MB of internal memory along with an 8 MB flash drive memory.
Design: The advanced design enables its use in areas with high interference levels. By combining the antenna emitter with the radio module/access point, a new level of versatility is achieved. The device is capable of operating in temperatures ranging from -40 to 70 degrees Celsius.
Antennas: The dual-band antenna, featuring a 300 mm diameter, offers a maximum gain of 22 dBi. The device is powered via PoE and includes one Ethernet 10/100 Mb/s port. It employs InnerFeed technology, which enhances bandwidth and interference resistance.
Key Features:
– Operates in the 5 GHz band
– 150 Mbps bandwidth
– 22 dBi antenna gain
– 20 km range
– Durable construction
– Supports router or bridge mode
– Easy installation
– Incorporates InnerFeed technology
– Utilizes AirMax technology
Installation: The PBE-M5-300 is designed for quick and easy installation. Setting up the AF-5X is straightforward and intuitive.
Usage: This device is highly versatile, capable of functioning in both Router and Bridge modes.
Comparison:
– PBE-M5-620
– Frequency Band: 5 GHz
– Antenna Gain: 29 dBi
– Dish Reflector: 620 mm
– Network Interface: 10/100/1000
– Throughput: 150+ Mbps
– Range: 30+ km
– PBE-M5-400
– Frequency Band: 5 GHz
– Antenna Gain: 25 dBi
– Dish Reflector: 400 mm
– Network Interface: 10/100/1000
– Throughput: 150+ Mbps
– Range: 25+ km
– PBE-M5-300
– Frequency Band: 5 GHz
– Antenna Gain: 22 dBi
– Dish Reflector: 300 mm
– Network Interface: 10/100
– Throughput: 150+ Mbps
– Range: 20+ km
– PBE-M2-400
– Frequency Band: 2.4 GHz
– Antenna Gain: 18 dBi
– Dish Reflector: 400 mm
– Network Interface: 10/100
– Throughput: 150+ Mbps
– Range: 20+ km
Manufacturer's Content: For more detailed information, refer to the manufacturer's documentation and manual.
| Mechanical | |
|---|---|
| Dimensions | 325 x 325 x 256 mm (12.8 x 12.8 x 10.1") |
| Weight | 1.2 kg (2.65 lb) |
| Enclosure material | UV-stabilized plastic |
| Mounting | Pole mount kit (Included) |
| Wind survivability | 200 km/h (125 mph) |
| Wind loading | 200.2 N @ 200 km/h (45 lbf @ 125 mph) |
| Hardware | |
| Networking interface | (1) 10/100 MbE port |
| Power method | Passive PoE 2-pair (4, 5+; 7, 8 return) |
| Power supply | 24V, 0.5A PoE adapter (Included) |
| Supported voltage range | 20–27V DC |
| Max. power consumption | 6W |
| ESD/EMP protection | Air/contact: ± 24 kV |
| LEDs | (1) Power, (1) LAN, (4) WLAN |
| Signal strength LEDs | Software-adjustable to correspond to custom RSSI levels |
| RoHS compliance | Yes |
| Salt fog test | IEC 68-2-11 (ASTM B117) Equivalent: MIL-STD-810 G method 509.5 |
| Vibration test | IEC 68-2-6 |
| Temperature shock test | IEC 68-2-14 |
| UV test | IEC 68-2-5 at 40° C (104° F) Equivalent: ETS 300 019-1-4 |
| Wind-driven rain test | ETS 300 019-1-4 Equivalent: MIL-STD-810 G method 506.5 |
| Ambient operating temperature | -40 to 70° C (-40 to 158° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| System | |
| Gain | 22 dBi |
| Channel sizes | 5/8/10/20/30/40 MHz |
| Max. VSWR | 1.5:1 |
| Polarization | Dual linear |
| Operating Frequency (MHz) | |
| Worldwide | 5150 – 5875 MHz |
| US/CA U-NII-1 U-NII-2A U-NII-2C U-NII-3 |
5150 – 5250 MHz 5250 – 5350 MHz 5470 – 5725 MHz 5725 – 5850 MHz |
