QNAP QSW-M1204-4C Network Switch Managed 10G Ethernet (100/1000/10000) Black

The QNAP QSW-M1204-4C is a managed switch designed for high-performance networking. It features basic switching RJ-45 Ethernet ports that support 10G Ethernet and are compatible with 100/1000/10000 Mbps. The switch comes with an RS-232 console port for easy management. It operates in full duplex mode, ensuring efficient data transmission. It has a MAC address table that can accommodate up to 32,000 entries and offers a substantial switching capacity of 240 Gbit/s. This switch supports a range of networking standards, including IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, and IEEE 802.3ad. It is also suitable for rack mounting, making it a versatile addition to any network infrastructure.

Management features

Switch type
Switch type
Managed
show more


Quality of Service (QoS) support
Yes
show more


Web-based management
Web-based management
Yes
show more

Ports & interfaces

Basic switching RJ-45 Ethernet ports type
Basic switching RJ-45 Ethernet ports type
10G Ethernet (100/1000/10000)
show more


Gigabit Ethernet (copper) ports quantity
1
show more


Combo SFP ports quantity
4
show more


SFP+ module slots quantity
8
show more


Console port
RS-232
show more

Network

Networking standards
Networking standards
IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
show more


10G support
10G support
Yes
show more


Full duplex
Full duplex
Yes
show more


Auto-negotiation
Yes
show more


Flow control support
Yes
show more


Spanning tree protocol
Yes
show more


VLAN support
VLAN support
Yes
show more


Virtual LAN features
Port-based VLAN
show more

Data transmission

Switching capacity
Switching capacity
240 Gbit/s
show more


Throughput
120 Gbit/s
show more


MAC address table
MAC address table
32000 entries
show more


Jumbo frames support
Yes
show more


Jumbo frames
9000
show more

Security

DHCP features
DHCP client
show more


Access Control List (ACL)
Yes
show more


IGMP snooping
Yes
show more

Design

Rack mounting
Rack mounting
Yes
show more


Product colour
Product colour
Black
show more


Reset button
Yes
show more


LED indicators
Activity, Link, Power, Speed, Status
show more


Number of fans
Number of fans
4 fan(s)
show more


Electromagnetic compatibility
Electromagnetic compatibility
CLASS A
show more

Performance

Firmware upgradeable
Yes
show more

Power

Power source
Power source
AC
show more


Power supply included
Power supply included
Yes
show more


AC input voltage
AC input voltage
100 – 240 V
show more


AC input frequency
50 – 60 Hz
show more


Power consumption (max)
Power consumption (max)
70 W
show more

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
0 – 40 °C
show more


Operating relative humidity (H-H)
5 – 95%
show more

Weight & dimensions

Width
Width
285 mm
show more


Depth
Depth
236.6 mm
show more


Height
Height
46.6 mm
show more


Weight
Weight
2.16 kg
show more

Packaging content

Cables included
AC
show more


User guide
Yes
show more

Certificates

Certification
FCC, CE, VCCI, BSMI, RCM, WEEE
show more

Logistics data

Harmonized System (HS) code
85176990
show more
