Mikrotik RB912R-2ND-LTM & R11E-4G Wireless Access Point 100 Mbit/s Black Power over Ethernet (PoE)

The LtAP Mini 4G Kit is a small, weatherproof wireless access point equipped with a built-in cellular modem, offering 4G (LTE) connectivity. It supports LTE FDD bands 3 (1800MHz), 7 (2600MHz), 20 (800MHz), and 31 (450MHz), as well as LTE TDD bands 41n (2500MHz), 42 (3500MHz), and 43 (3700MHz).

This device features a 10/100 Ethernet LAN port, allowing you to connect to the built-in 802.11b/g/n wireless network and access the LTE network from your phone or any other wireless device. It also provides one 10/100 Ethernet LAN port for wired connections. The RS232 serial port offers console access for debugging.

The LtAP Mini 4G Kit comes with a special enclosure and a wall mounting kit, two SIM slots for switching between cellular providers, and integrated GPS support. This makes it ideal for use in vehicles such as cars, buses, or trains. Please note that an external GPS antenna is required for GPS functionality, available separately (product code GPSANT).

It features two internal antennas connected to the LTE card via u.FL connectors. These can be unplugged to add your own external LTE antenna for improved coverage. The unit supports several power options: 9-30 V PoE-in via the Ethernet port, DC jack, and microUSB.

With a built-in GPS module, you can track your vehicle's location in real-time. A simple tracking application example is provided in the RouterOS documentation to assist in developing your platform.

Additional Product Notes: The maximum data transfer rate is 100 Mbit/s, the Wi-Fi data rate is up to 54 Mbit/s, and the Ethernet LAN data rates are 10/100 Mbit/s.
