MikroTik KNOT IoT Lora8 Kit, IoT Gateway, Bluetooth, LoRa, RouterOS

The Mikrotik KNOT LR8 Kit (RB924IR-2ND-BT5_BG77_R11E-LR8) is a versatile network solution designed for a range of applications. Available in a sleek white finish, this compact device fits seamlessly into any setting while delivering strong performance. It has an IP20 protection rating, making it suitable for indoor use, and is IC-certified to meet industry standards.

Powered by a QCA9531 processor with a speed of 650 MHz, the KNOT LR8 Kit provides reliable processing for efficient data management. It comes with 64 MB of internal memory, enabling smooth multitasking. The device can handle data transfer speeds up to 100 Mbit/s via its Ethernet LAN interface, suitable for various networking functions.

The kit supports IEEE 802.11b, IEEE 802.11g, and IEEE 802.11n communication standards on a 2.4 GHz Wi-Fi frequency, with a maximum antenna gain of 1.5 dBi for a stable and reliable wireless connection. Additionally, it includes a NanoSIM card slot for versatile connectivity options.

Built for durability, the Mikrotik KNOT LR8 Kit has an MTBF (Mean Time Between Failures) of 200,000 hours, making it a wise choice for both personal and professional use. It also features an RS-485 SCSI interface, enhancing its compatibility with a variety of devices to cater to diverse user needs across different environments.

Design

Product colour
Product colour
White
show more


International Protection (IP) code
International Protection (IP) code
IP20
show more

Features

Antenna gain level (max)
Antenna gain level (max)
1.5 dBi
show more


GPS (satellite)
GPS (satellite)
Yes
show more


Mean time between failures (MTBF)
Mean time between failures (MTBF)
200000 h
show more

Performance

Processor model
Processor model
QCA9531
show more


Built-in processor
Built-in processor
Yes
show more


Processor frequency
Processor frequency
650 MHz
show more


Number of processors installed
Number of processors installed
1
show more


Internal memory
Internal memory
64 MB
show more


Flash memory
128 MB
show more

Network

Ethernet LAN data rates
Ethernet LAN data rates
100 Mbit/s
show more


Networking standards
Networking standards
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
show more


Wi-Fi band
Wi-Fi band
Single-band (2.4 GHz)
show more


Top Wi-Fi standard
Top Wi-Fi standard
Wi-Fi 4 (802.11n)
show more


Wi-Fi
Wi-Fi
Yes
show more


WLAN data transfer rate (max)
300 Mbit/s
show more


WLAN data transfer rates supported
300 Mbit/s
show more


Bluetooth version
Bluetooth version
5.2
show more


Bluetooth
Bluetooth
Yes
show more


Frequency band
Frequency band
2.4 GHz
show more

Ports & interfaces

SIM card slot
SIM card slot
Yes
show more


SIM card type
NanoSIM
show more


Serial interface type
RS-485
show more


Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
2
show more

Power

Power consumption (max)
Power consumption (max)
23 W
show more


DC input voltage
12 – 57 V
show more


Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
show more

Software

Compatible operating systems
Compatible operating systems
RouterOS
show more

Weight & dimensions

Height
Height
26 mm
show more


Depth
Depth
87 mm
show more


Width
Width
122 mm
show more

Packaging content

Quick start guide
Quick start guide
Yes
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
-40 – 70 °C
show more

Sustainability

Sustainability compliance
Yes
show more

Technical details

BeiDou
Yes
show more


Galileo
Yes
show more

Certificates

Compliance certificates
CE, Federal Communications Commission (FCC), RoHS
show more


Certification
IC
show more
