The Ubiquiti RD-5G30-LW is an efficient solution with a perfected design, featuring a directional antenna with a lightweight construction. Operating in the 5 GHz band, it facilitates the creation of efficient connections. The Ubiquiti RD-5G30-LW is capable of establishing efficient, long-distance radio links utilizing MIMO 2×2 technology in the 5 GHz band.
Construction: The RocketDish 5G30-LW is a lighter version of the popular RD-5G30 solution, weighing only 7.4 kg. Its innovative casing is crafted from an alloy resistant to corrosion and other adverse effects.
Build: The antenna is highly resistant to unfavorable weather conditions, which ensures a long and trouble-free life cycle. Its industrial design is innovative and performs exceptionally in scenarios demanding reliable and efficient operation.
Easy Installation: The Ubiquiti antenna is notable for its easy installation with Rocket, requiring no specialized tools. It comes with a handle that allows for precise positioning of the antenna.
Use: The device is commonly used for creating Point-to-Point and Point-to-Multipoint connections.
Key Features:
– Operates in the 5 GHz band
– 30 dBi gain
– Dual Linear polarization
– Lightweight construction
– Easy installation
Comparison:
– RD-2G24: Frequency 2.4 GHz, Gain 24 dBi, Dual-Linear Polarization, Max. VSWR 1.6:1, F/B Ratio 28 dB, Dimensions 650 x 650 x 295 mm
– RD-3G26: Frequency 3 GHz, Gain 26 dBi, Dual-Linear Polarization, Max. VSWR 1.4:1, F/B Ratio 33 dB, Dimensions 650 x 650 x 300 mm
– RD-5G30: Frequency 5 GHz, Gain 30 dBi, Dual-Linear Polarization, Max. VSWR 1.4:1, F/B Ratio 34 dB, Dimensions 650 x 650 x 304 mm
– RD-5G30-LW: Frequency 5 GHz, Gain 30 dBi, Dual-Linear Polarization, Max. VSWR 1.6:1, F/B Ratio 30 dB, Dimensions 650 x 650 x 386 mm
– RD-5G34: Frequency 5 GHz, Gain 34 dBi, Dual-Linear Polarization, Max. VSWR 1.4:1, F/B Ratio 42 dB, Dimensions 1050 x 1050 x 421 mm
Note: Dimensions exclude the pole mount and Rocket (sold separately).
Manufacturer's Content: More information is available in the manufacturer's documentation and manual. Specifications are provided for further detail.
| RD-5G30-LW | |
|---|---|
| Dimensions | 650 x 650 x 386 mm (25.6 x 25.6 x 15.2") |
| Weight | 7.4 kg (16.31 lb) |
| Frequency Range | 5.1 – 5.9 GHz |
| Gain | 30 dBi |
| HPOL Beamwidth | 5.8° (3 dB) |
| VPOL Beamwidth | 5.8° (3 dB) |
| F/B Ratio | 30 dB |
| Max. VSWR | 1.6:1 |
| Wind Loading | 790 N @ 200 km/h (178 lbf @ 125 mph) |
| Wind Survivability | 200 km/h (125 mph) |
| Polarization | Dual-Linear |
| Cross-pol Isolation | 35 dB Min. |
| ETSI Specification | EN 302 326 DN2 |
| Mounting | Universal Pole Mount, Rocket Bracket, and Weatherproof RF Connectors Included |
