Zyxel RGS100-12P, 5 Port Unmanaged PoE Switch, 120 Watt PoE, DIN Rail, IP30, 12-58V DC

The Zyxel RGS100-5P is an unmanaged switch that operates at Layer 2. It features four basic switching RJ-45 Ethernet ports, each supporting Gigabit Ethernet (10/100/1000). It offers full duplex communication. The switch can handle up to 2000 MAC address entries and has a switching capacity of 10 Gbit/s. It is compliant with several networking standards, including IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, and IEEE 802.3x. The switch supports a DC input voltage range from 12 to 58 V and includes Power over Ethernet (PoE) capabilities. It is designed for flexibility in installation, allowing for both wall mounting and rack mounting.

Management features

Switch type
Switch type
Unmanaged
show more


Switch layer
Switch layer
L2
show more

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
Basic switching RJ-45 Ethernet ports quantity
4
show more


Basic switching RJ-45 Ethernet ports type
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
show more


SFP module slots quantity
1
show more


Fiber optic connector
Fiber optic connector
SFP
show more

Network

Networking standards
Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
show more


10G support
10G support
No
show more


Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
show more


Full duplex
Full duplex
Yes
show more


MAC address auto-learning supported
Yes
show more


Auto-negotiation
Yes
show more


Auto MDI/MDI-X
Auto MDI/MDI-X
Yes
show more


Flow control support
Yes
show more

Optical fiber

Fiber ethernet cabling technology
1000BASE-X
show more


Transmission distance (max)
40 km
show more

Data transmission

Switching capacity
Switching capacity
10 Gbit/s
show more


Throughput
7.44 Mpps
show more


MAC address table
MAC address table
2000 entries
show more


Store-and-forward
Yes
show more


Jumbo frames support
Yes
show more


Jumbo frames
9000
show more


Packet buffer memory
0.25 MB
show more

Multicast features

Multicast support
Yes
show more

Design

Rack mounting
Rack mounting
Yes
show more


Product colour
Product colour
Black
show more


Housing material
Housing material
Metal
show more


DIN rail mounting
Yes
show more


Wall mountable
Wall mountable
Yes
show more


International Protection (IP) code
International Protection (IP) code
IP30
show more

Performance

Plug and Play
Plug and Play
Yes
show more


Mean time between failures (MTBF)
Mean time between failures (MTBF)
568430 h
show more

Power

DC input voltage
12 – 58 V
show more


Input voltage
Input voltage
12 – 58 V
show more


Power consumption (max)
Power consumption (max)
125 W
show more


Power protection features
Power protection features
Short circuit
show more

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
show more


Power over Ethernet plus (PoE+) ports quantity
4
show more


Total Power over Ethernet (PoE) budget
120 W
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
-40 – 75 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 85 °C
show more


Operating relative humidity (H-H)
5 – 95%
show more


Storage relative humidity (H-H)
5 – 90%
show more


Heat dissipation
Heat dissipation
42625 BTU/h
show more

Weight & dimensions

Width
Width
29.1 mm
show more


Depth
Depth
107.3 mm
show more


Height
Height
139 mm
show more


Weight
Weight
500 g
show more

Packaging content

Rack mount kit
Yes
show more

Packaging data

Wall mounting kit
Yes
show more


Package width
Package width
70 mm
show more


Package depth
Package depth
177.8 mm
show more


Package height
Package height
205 mm
show more


Package weight
Package weight
700 g
show more

Logistics data

Harmonized System (HS) code
85176990
show more
