APC Smart-UPS SRT Lithium-Ion 1000VA/900W 2400Wh RM 4U 230V Long Runtime 145 Minutes by 900 Watt

The APC Smart-UPS On-Line is a high-performance, 1000VA, lithium-ion UPS designed for rackmount installation, occupying a 4U space. It operates at 230V and provides 8 C13 IEC outlets, with an additional SmartSlot for enhanced functionality. This model features extended long runtime and comes with a rail kit for easy installation. Utilizing a double-conversion (online) topology, it offers an output power capacity of 1 kVA and delivers a consistent output power of 900 W. The system includes C13 coupler AC outlet types and is powered by a C14 coupler plug, accommodating a total of 8 AC outlets. The UPS is powered by lithium-ion battery technology, boasting a battery capacity of 2400 Ah and a voltage of 48 V. It is versatile with a rackmount/tower form factor and comes in black and silver colors, fitting into a 4U rack space. The product meets CE and RoHS compliance standards.

Features

UPS topology
UPS topology
Double-conversion (Online)
show more


Output power capacity
Output power capacity
1 kVA
show more


Output power
Output power
900 W
show more


Waveform
Sine
show more


Input operation voltage (min)
Input operation voltage (min)
160 V
show more


Input operation voltage (max)
Input operation voltage (max)
275 V
show more


Input frequency
Input frequency
40/70 Hz
show more


Output operation voltage (min)
Output operation voltage (min)
220 V
show more


Output operation voltage (max)
Output operation voltage (max)
230 V
show more


Output frequency
50/60 Hz
show more


Surge energy rating
Surge energy rating
340 J
show more


Crest factor
3:1
show more


Emergency Power Off (EPO)
Yes
show more


Noise level
Noise level
50 dB
show more


Detachable power cord
Yes
show more


Power source type
Power source type
AC
show more

Ports & interfaces

AC outlet types
AC outlet types
C13 coupler
show more


Power plug
Power plug
C14 coupler
show more


AC outlets quantity
AC outlets quantity
8 AC outlet(s)
show more

Battery

Battery technology
Battery technology
Lithium-Ion (Li-Ion)
show more


Battery capacity
Battery capacity
2400 Ah
show more


Battery voltage
Battery voltage
48 V
show more


Typical backup time at full load
Typical backup time at full load
136 min
show more


Typical backup time at half load
Typical backup time at half load
252 min
show more


Battery life (max)
10 year(s)
show more

Design

Form factor
Form factor
Rackmount/Tower
show more


Rack capacity
Rack capacity
4U
show more


Modular
Yes
show more


Cable length
Cable length
1.83 m
show more


Product colour
Product colour
Black, Silver
show more


Control type
Control type
Buttons
show more


Display type
Display type
LCD
show more


International Protection (IP) code
International Protection (IP) code
IP20
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
0 – 40 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-15 – 45 °C
show more


Operating relative humidity (H-H)
0 – 95%
show more


Storage relative humidity (H-H)
0 – 95%
show more


Operating altitude
0 – 3048 m
show more


Non-operating altitude
0 – 15240 m
show more

Sustainability

Sustainability certificates
Green Premium
show more

Packaging content

Rack mount kit
Yes
show more

Certificates

Compliance certificates
CE, RoHS
show more


Certification
RoHS, CE
show more

Weight & dimensions

Width
Width
432 mm
show more


Depth
Depth
59 mm
show more


Height
Height
171 mm
show more


Weight
Weight
40.7 kg
