Supermicro SuperStorage Server 5029P-E1CTR12L Intel C622 LGA 3647 Socket P Rack 2U Black

The Supermicro SuperStorage Server 5029P-E1CTR12L is equipped with an Intel C622 motherboard chipset and features an LGA 3647 (Socket P) processor socket. It is compatible with Intel® Xeon® processor series. This server supports DDR4-SDRAM memory types, with a maximum internal memory capacity of 1 TB and a maximum RDIMM memory of 192 GB. It accommodates storage drive sizes of 3.5 inches and supports M.2 and Serial ATA III storage drive interfaces. The system offers RAID levels 0, 1, 5, and 10 for enhanced storage configurations. The on-board graphics card is the Aspeed AST2500 model. For networking capabilities, it includes a 10 Gigabit Ethernet interface, supporting Ethernet LAN data rates of up to 10000 Mbit/s and utilizing copper ethernet cabling technology with 10GBASE-T.

Processor

Built-in processor
Built-in processor
No
show more


Motherboard chipset
Motherboard chipset
Intel C622
show more


Processor socket
Processor socket
LGA 3647 (Socket P)
show more


Number of processors supported
Number of processors supported
1
show more


Compatible processor series
Compatible processor series
Intel® Xeon®
show more

Memory

Number of DIMM slots
Number of DIMM slots
8
show more


Supported memory types
Supported memory types
DDR4-SDRAM
show more


Maximum internal memory
Maximum internal memory
1 TB
show more


Maximum RDIMM memory
192 GB
show more


Supported RDIMM clock speeds
2133,2400,2666 MHz
show more


ECC
ECC
Yes
show more

Storage

Hot-swap HDD bays
Hot-swap HDD bays
Yes
show more


Number of 3.5" bays
Number of 3.5
12
show more


Storage drive sizes supported
Storage drive sizes supported
3.5"
show more


Supported storage drive interfaces
M.2, Serial ATA III
show more


RAID levels
RAID levels
0, 1, 5, 10
show more

Graphics

On-board graphics card model
On-board graphics card model
Aspeed AST2500
show more

Network

Ethernet interface type
10 Gigabit Ethernet
show more


Ethernet LAN
Ethernet LAN
Yes
show more


Ethernet LAN data rates
Ethernet LAN data rates
10000 Mbit/s
show more


Copper ethernet cabling technology
10GBASE-T
show more


LAN controller
Intel® X557, Intel® X722
show more

Ports & interfaces

USB 2.0 ports quantity
USB 2.0 ports quantity
2
show more


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
show more


Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
2
show more


IPMI LAN (RJ-45) port
Yes
show more


VGA (D-Sub) ports quantity
VGA (D-Sub) ports quantity
1
show more


Serial ports quantity
Serial ports quantity
1
show more


Number of SATA III connectors
Number of SATA III connectors
10
show more

Expansion slots

PCI Express slots version
2.0, 3.0
show more


PCI Express x4 slots
1
show more


PCI Express x8 slots
2
show more


PCI Express x16 slots
1
show more

Features

Backplanes support
Yes
show more

Logistics data

Harmonized System (HS) code
84714100
show more

Technical details

Compliance certificates
RoHS
show more

BIOS

BIOS type
BIOS type
UEFI AMI
show more

Design

Chassis type
Chassis type
Rack (2U)
show more


Product colour
Product colour
Black
show more


LED indicators
HDD, Heating, Network, Power, Power fail
show more


Fan diameter
Fan diameter
8 cm
show more


Number of fans
Number of fans
3 fan(s)
show more

Power

Power supply
Power supply
800 W
show more


Redundant power supply (RPS) support
Redundant power supply (RPS) support
Yes
show more


Number of redundant power supplies installed
2
show more

Operational conditions

Storage relative humidity (H-H)
5 – 95%
show more


Operating relative humidity (H-H)
8 – 90%
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 60 °C
show more


Operating temperature (T-T)
Operating temperature (T-T)
10 – 35 °C
show more
