APC SURT001 Isolation Transformer

The APC Smart-UPS RT Isolation Transformer is designed to provide reliable power protection and performance. It has a capacity of 3000VA, with both input and output voltages of 230V. This model includes one IEC jumper and one IEC 60320 C19 outlet for versatile connectivity options. The transformer features a C20 coupler for the AC inlet type and a C19 coupler for the AC outlet type, ensuring compatibility with different equipment. The unit's dimensions are a width of 432 mm, a depth of 66 mm, and a height of 130 mm.

Features

AC inlet type
C20 coupler
show more


AC outlet types
AC outlet types
C19 coupler
show more


AC input voltage
AC input voltage
230 V
show more


AC input frequency
50 – 60 Hz
show more


AC output voltage
230 V
show more


Input current (max)
16 A
show more


Rack capacity
Rack capacity
3U
show more


Rack mounting
Rack mounting
Yes
show more


Housing colour
Housing colour
Black
show more


Number of output IEC jumpers
1
show more


Load capacity
3000 VA
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
0 – 40 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-25 – 65 °C
show more


Operating relative humidity (H-H)
0 – 95%
show more


Storage relative humidity (H-H)
0 – 95%
show more


Non-operating altitude
0 – 15000 m
show more


Operating altitude
0 – 3000 m
show more

Weight & dimensions

Width
Width
432 mm
show more


Depth
Depth
66 mm
show more


Height
Height
130 mm
show more


Weight
Weight
56.8 kg
show more

Technical details

Compliance certificates
REACH, RoHS
show more
